LP16 10A 5Pin Male Plug IP67 Waterproof Connector

397.0 INR/pieces

Get a Price/Quote

Product Details:

Interface Circular screw lock male plug
Components Housing, 5-pin insert, sealing ring, screw terminal
Power Source External electric circuit
Features Waterproof, dustproof, corrosion resistant, easy installation
Power Supply Wired, external source
Output To compatible female connector
Input 5 Pin male plug
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP16 10A 5Pin Male Plug IP67 Waterproof Connector Price And Quantity

Price 397.0 INR/pieces
Minimum Order Quantity 100 pieces

LP16 10A 5Pin Male Plug IP67 Waterproof Connector Product Specifications

Components Housing, 5-pin insert, sealing ring, screw terminal
Power Source External electric circuit
Interface Circular screw lock male plug
Product Type Waterproof circular connector
Weight Approx. 25g
Current Rating 10A
Features Waterproof, dustproof, corrosion resistant, easy installation
Supply Voltage Up to 250V
Power Supply Wired, external source
Output To compatible female connector
Frequency 50/60Hz
Input 5 Pin male plug
IP Rating IP67
Dimension (L*W*H) Approx. 60mm x 24mm (diameter)
Application LED lighting, outdoor equipment, power distribution, signal transmission
Capacity Up to 10A current
Operating Temperature -40C to +80C
Color Black, Grey
Usage Industrial automation, machinery, outdoor applications
Function Electrical power and signal connection
Thickness Standard wall gauge, specific value not provided
Rated Voltage 250V AC
Size LP16 Series standard (approx. 16mm diameter)

Contact Resistance 5m
Mechanical Life Up to 500 cycles of insertion/withdrawal
Contact plating Gold plated for corrosion resistance
Connector Gender Male (plug)
Mating Cycle 500 times
Sealing Method Silicone O-ring
Material High quality plastic shell and brass contacts
Locking System Threaded screw lock
Installation Method Panel mount or cable mount
Flame Retardant Level UL94-V0
Standards Compliance RoHS compliant
Cable Range 4mm - 6.5mm cable diameter
Insulation Resistance >500M at 500V DC
Mounting Type Inline cable mount

LP16 10A 5Pin Male Plug IP67 Waterproof Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:Easy locking type
Insertion and extraction force:1.8N Max
Temperature and humidity:-4080C, 40C, 85%RH
Mating cycle:1700 times
Contact dimension:Phi 1.5*3
Operating Voltage:400V
Diameter range:79mm

Exceptional Durability and Protection

The LP16 connector features an IP67 waterproof and dustproof design, making it highly reliable for both indoor and outdoor environments. Its robust plastic housing, gold-plated brass contacts, and flame retardant performance (UL94-V0) ensure longevity, safety, and consistent operation even in challenging conditions. With up to 500 mechanical mating cycles, this connector is built for sustained, repeated use in demanding settings.

Flexible Installation and Use

Designed for easy panel or cable mounting, the LP16 is adaptable for inline connections and external wiring. Its silicone O-ring provides a secure seal, while the threaded screw lock system ensures stability and simple assembly. Ideal for applications ranging from machinery automation to outdoor LED lighting, this connector accommodates diverse cable ranges (4mm-6.5mm) and maintains reliable contacts with every connection.

Reliable Performance with Safety Standards

With a maximum operating voltage of 250V AC and current capacity of 10A, the LP16 connector offers high electrical performance and safety. Compliance with RoHS standards, outstanding insulation resistance (>500M at 500V DC), and gold-plated contacts make it suitable for sensitive or critical power and signal applications. Users benefit from its corrosion resistance and dependable operation in harsh environments.

FAQ's of LP16 10A 5Pin Male Plug IP67 Waterproof Connector:

Q: How do I install the LP16 5Pin Male Plug connector?

A: You can install the LP16 connector using either panel mount or cable mount methods. The threaded screw lock system ensures stable assembly, while the silicone O-ring provides a waterproof seal. Simply connect the cable (4mm-6.5mm diameter), secure the contacts, and fasten the connector to its mating component.

Q: What types of applications are suitable for the LP16 connector?

A: This connector is well-suited for industrial automation, machinery, outdoor equipment, LED lighting setups, power distribution, and signal transmission. Its IP67 waterproof rating and durable materials make it highly effective in harsh or outdoor environments.

Q: When should I use this type of waterproof connector?

A: Use the LP16 connector whenever you need reliable electrical power or signal transmission in environments exposed to moisture, dust, or external weather, such as outdoor installations or industrial machinery. Its high IP67 rating ensures reliable operation in such scenarios.

Q: Where does the LP16 5Pin Male Plug find its primary use?

A: The LP16 is primarily used in industrial and outdoor applications across India and internationally, particularly by distributors, manufacturers, and installers needing secure power or signal connections for machinery, power panels, or lighting systems.

Q: What are the benefits of using gold-plated contacts in this connector?

A: Gold-plated brass contacts in the LP16 connector offer enhanced corrosion resistance and exceptionally low contact resistance, ensuring stable electrical performance and a longer service life in demanding conditions.

Q: How long can I expect the LP16 connector to last?

A: The LP16 connector is rated for up to 500 cycles of insertion and withdrawal, thanks to its robust construction and mechanical design. Regular use within specified conditions ensures longevity and consistent performance.

Q: What process ensures the LP16's water and dust resistance?

A: The LP16 achieves IP67 protection through its precision-engineered plastic housing, a silicone O-ring seal, and a threaded screw lock system. This combination keeps out water and dust even during temporary submersion, providing long-term environmental protection.
