LP20 10A 7Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal

572.0 INR/Piece

Get a Price/Quote

Product Details:

Interface Solder terminal
Input 7 pin female socket
Output Panel or cable connection
Components Metal shell, 7 solder terminals, silicone seal
Power Source Electrical connection (power distribution)
Usage Industrial automation, equipment, cable assemblies
Operating Temperature -40C to +80C
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 10A 7Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 572.0 INR/Piece

Termination Solder
Contact Resistance 2.5m
Waterproof Grade IP67 (can withstand temporary immersion)
Material - Insert High performance engineering plastic
Vibration Resistance Yes
Mounting Type Panel mount, flange type
Material - Seal Silicone rubber
Flame Retardant Rating UL94-V0
Working Humidity 95% RH (non-condensing)
Number of Pins 7 (female)
Mating Cycle >500 times
Material - Shell Zinc alloy with surface plating
Insulation Resistance 2000M (at 500V DC)
Locking Mechanism Threaded coupling
Contact Material Copper alloy, gold plated
Anti-corrosion Yes

LP20 10A 7Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Product Specifications

Usage Industrial automation, equipment, cable assemblies
Color Metallic silver/black
Weight Approx. 42g
Interface Solder terminal
Thickness Shell thickness approx. 1.5mm
Supply Voltage Rated up to 500V
Frequency 50/60Hz
Operating Temperature -40C to +80C
Power Supply AC/DC
IP Rating IP67
Features Waterproof, dustproof, vibration resistant, easy installation
Dimension (L*W*H) Flange diameter ~30mm, panel hole ~20mm
Product Type Waterproof power connector
Application Outdoor, industrial, or harsh environment connections
Current Rating 10A
Input 7 pin female socket
Capacity 10A (Maximum current capacity)
Rated Voltage 500V AC
Size M20 (flange mount size)
Output Panel or cable connection
Function Power and signal connection
Power Source Electrical connection (power distribution)
Components Metal shell, 7 solder terminals, silicone seal

Termination Solder
Contact Resistance 2.5m
Waterproof Grade IP67 (can withstand temporary immersion)
Material - Insert High performance engineering plastic
Vibration Resistance Yes
Mounting Type Panel mount, flange type
Material - Seal Silicone rubber
Flame Retardant Rating UL94-V0
Working Humidity 95% RH (non-condensing)
Number of Pins 7 (female)
Mating Cycle >500 times
Material - Shell Zinc alloy with surface plating
Insulation Resistance 2000M (at 500V DC)
Locking Mechanism Threaded coupling
Contact Material Copper alloy, gold plated
Anti-corrosion Yes

LP20 10A 7Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:400V
Withstanding voltage:2500V
Mating cycle:1700 Times
Temperature and humidity:-40+80C; 40C, 85%RH
Contact dimension:Phi 2.7x3
Screw torque:42-53 (N.m)

Exceptional Durability for Harsh Environments

Constructed with a metal shell and silicone rubber seal, the LP20 7Pin Female Socket achieves IP67 waterproofing-capable of withstanding temporary immersion and exposure to dust. Its anti-corrosion properties, vibration resistance, and wide operating temperature range make it highly suitable for outdoor and industrial installations.

Secure and Reliable Connections

The connector's threaded coupling ensures a firm, stable connection even under vibration or movement. Gold-plated copper contacts guarantee low resistance and optimal conductivity, while the flange mount provides easy and secure panel installation.

Versatile Applications for Power and Signal

Engineered for up to 10A and 500V (AC/DC), this connector is well-suited for industrial automation, cable assemblies, power supply modules, machinery, and other equipment requiring steadfast signal and power links in challenging environments.

FAQ's of LP20 10A 7Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal:

Q: How is the LP20 7Pin Female Socket typically installed?

A: This connector is designed for panel mounting and features a flange type for secure attachment. You simply mount it into a panel hole with a diameter of approximately 20mm and secure it using screws through the flange. The solder terminals allow for direct wire attachment to the seven pins.

Q: What makes this connector suitable for outdoor and industrial use?

A: The LP20 socket offers IP67 waterproof and dustproof protection, meaning it can endure temporary immersion and harsh weather conditions. Its robust zinc alloy shell, corrosion resistance, vibration capabilities, and flame retardant rating UL94-V0 make it ideal for demanding environments.

Q: When should I choose this product over standard connectors?

A: Choose the LP20 7Pin Female Socket when your application requires reliable connectivity in tough conditions-such as high humidity, frequent vibrations, risk of water exposure, or fluctuating temperatures. Its design ensures consistent performance in industrial automation or outdoor equipment.

Q: Where can the LP20 7Pin Female Socket be used?

A: This connector is suitable for use in a variety of settings, including power distribution panels, control cabinets, cable assemblies, automation machinery, and outdoor installations where secure, waterproof, and dustproof connections are critical.

Q: What is the process for wiring the LP20 connector?

A: To wire the connector, solder your cables to the seven internal terminals, ensuring each connection is secure and insulated. Once soldered, mount the connector to the panel and use the threaded coupling to mate it with the corresponding plug, creating a sealed and vibration-resistant connection.

Q: What are the primary benefits of using this socket?

A: The main advantages include excellent electrical conductivity from gold-plated contacts, enhanced safety with flame retardancy and waterproofing, resistance to environmental stressors like vibration and corrosion, and a long service life with over 500 mating cycles.
