LP20 500V 20A 4Pin Male Socket IP67 Waterproof Power Connector

377.0 INR/Piece

Get a Price/Quote

Product Details:

Features Waterproof, Dustproof, Vibration Resistant, Screw Locking
Power Source External Power Supply
Operating Temperature -40C to +80C
Components Connector Body, Pins, Locking Nut, Sealing Cap
Usage Outdoor Electrical Applications
Input 4-Pin Male Socket
Output To 4-pin Female Connector
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 500V 20A 4Pin Male Socket IP67 Waterproof Power Connector Price And Quantity

Minimum Order Quantity 100 Piece
Price 377.0 INR/Piece

Sealing Method Silicone Rubber Gasket
Mounting Type Panel Mount with Threaded Lock Nut
Mating Cycle Durability >500 mating cycles
Connector Gender Male
Number of Pins 4
Wire Size Compatibility Up to 2.5mm2 (AWG 14)
Ingress Protection Totally protected against dust and temporary immersion in water (IP67)
Shell Material High-Performance Thermoplastic
Contact Resistance 2.5m
Flame Resistance UL94-V0
Insulation Resistance >2000M at 500V DC
Contact Material Copper Alloy (Gold Plated)
Connector Type Circular, Panel Mount

LP20 500V 20A 4Pin Male Socket IP67 Waterproof Power Connector Product Specifications

Weight Approx. 60g
Power Source External Power Supply
Components Connector Body, Pins, Locking Nut, Sealing Cap
Operating Temperature -40C to +80C
Rated Voltage 500V
Current Rating 20A
Function Waterproof Power Connection
Features Waterproof, Dustproof, Vibration Resistant, Screw Locking
Thickness Standard
Application Industrial Equipment, Power Distribution, LED Lighting
Frequency 50-60 Hz
Interface Panel Mount, Male Socket
Dimension (L*W*H) Approximately 70mm x 33mm x 33mm
Supply Voltage 500V Max
Power Supply AC/DC
Output To 4-pin Female Connector
Product Type Power Connector
Capacity 20A
Input 4-Pin Male Socket
Usage Outdoor Electrical Applications
IP Rating IP67
Size Standard LP20
Color Black and Blue

Sealing Method Silicone Rubber Gasket
Mounting Type Panel Mount with Threaded Lock Nut
Mating Cycle Durability >500 mating cycles
Connector Gender Male
Number of Pins 4
Wire Size Compatibility Up to 2.5mm2 (AWG 14)
Ingress Protection Totally protected against dust and temporary immersion in water (IP67)
Shell Material High-Performance Thermoplastic
Contact Resistance 2.5m
Flame Resistance UL94-V0
Insulation Resistance >2000M at 500V DC
Contact Material Copper Alloy (Gold Plated)
Connector Type Circular, Panel Mount

LP20 500V 20A 4Pin Male Socket IP67 Waterproof Power Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting Mode:Latching Lock connect
Cable Specification:2.5mm2 4mm2 /1412AWG
Diameter Range:9mm13mm
Operating Voltage:500V
Withstand Voltage(AC.V)1min:2500V
Durability:> 1500 mating & unmating cycles
Temperature Rating:-40C80C

Waterproof Reliability for Outdoor Power

With an IP67 rating, the LP20 4Pin Male Socket delivers dependable waterproof and dustproof performance, making it ideal for outdoor installations and harsh environments. The silicone rubber gasket and threaded lock nut ensure a secure and tight seal, providing peace of mind when powering industrial equipment, LED lighting, or electrical systems exposed to the elements.

Improved Safety and Durability

Built from high-performance thermoplastic and gold-plated copper alloy contacts, this connector provides outstanding electrical conductivity, minimized contact resistance, and exceptional flame resistance (UL94-V0). Its robust design allows for safe operation in temperature ranges from -40C to +80C and ensures more than 500 mating cycles, making it perfect for repeated use in demanding settings.

Easy Installation and Versatile Usage

The LP20's circular, panel-mount interface with a screw-locked nut facilitates straightforward installation onto equipment panels. Its 4-pin setup allows for seamless AC or DC power connection, and compatibility with wire sizes up to 2.5mm2 (AWG 14) suits a wide range of industrial applications, including power distribution, controls, and illumination.

FAQ's of LP20 500V 20A 4Pin Male Socket IP67 Waterproof Power Connector:

Q: How is the LP20 4Pin Male Socket installed on panels?

A: The LP20 connector features a panel mount design with a threaded locking nut. Simply fit the connector into the pre-cut panel hole, secure it with the provided nut, and tighten for a stable, waterproof connection.

Q: What benefits does the gold-plated copper alloy contact provide?

A: Gold-plated copper alloy contacts ensure low contact resistance, excellent conductivity, and high corrosion resistance, contributing to reliable power transmission and a longer connector lifespan.

Q: Where can this connector be effectively used?

A: This socket is engineered for outdoor and industrial settings, including power distribution panels, LED lighting installations, and equipment exposed to moisture, dust, or vibrations.

Q: What power and voltage ratings are supported by the LP20 connector?

A: It supports up to 20A current and 500V AC/DC voltage, accommodating both high-power devices and standard machinery requiring a secure, waterproof connection.

Q: How does the IP67 rating benefit outdoor electrical applications?

A: The IP67 rating means the connector is completely protected against dust ingress and can withstand temporary immersion in water, making it exceptionally reliable for outdoor or demanding environments.

Q: What is the connector's mating cycle durability, and why is it important?

A: Withstanding over 500 mating cycles, the LP20 ensures repeated, secure connections and disconnections without performance degradation-ideal for maintenance-intensive or frequently serviced equipment.
