USB A TYPE FEMALE RA PCB 9 Pin Version 3.0

30 INR/Piece

Get a Price/Quote

Product Details:

Connector USB A Type Female, Right Angle
Female End Type USB A Type Female
Temperature Operating: -40C to +85C
Material Copper Alloy (contacts), Stainless Steel (shell), Thermoplastic (housing)
Voltage Rating 30V AC (RMS) max
Application USB 3.0 high-speed data transfer, PCB mounting
Connector Type USB Type A Female 3.0, Right Angle, Through Hole
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

USB A TYPE FEMALE RA PCB 9 Pin Version 3.0 Price And Quantity

Price 30 INR/Piece
Minimum Order Quantity 100 Piece

Current Rating 1.8A max
Insulation Resistance 1000 M min at 500V DC
LED Indicator No
Contact Resistance 30 m max
Compliance RoHS Compliant
Standard USB 3.0 SuperSpeed
Contact Plating Gold over Nickel
Cover/Cap Included No
Dielectric Withstanding Voltage 750V AC/minute
Number of Pins 9
Mating Cycles 1500 cycles minimum
Mounting Style Right Angle, Through Hole, PCB Mount

USB A TYPE FEMALE RA PCB 9 Pin Version 3.0 Product Specifications

Number of Conductor 9
Cable Type N/A (Connector only)
Connector Type USB Type A Female 3.0, Right Angle, Through Hole
Jacket Material N/A (Connector only)
Insulation High-temperature thermoplastic
Wire Gauge N/A (Connector only, no cable)
Application USB 3.0 high-speed data transfer, PCB mounting
Voltage Rating 30V AC (RMS) max
Material Copper Alloy (contacts), Stainless Steel (shell), Thermoplastic (housing)
Temperature Operating: -40C to +85C
Length N/A (PCB Mount)
Flame Resistance Level UL94V-0
Sheild Yes, Metal Shielded
Outer Diameter N/A (Connector only)
Cable Length N/A (Connector only)
Color Blue
Female End Type USB A Type Female
Connector USB A Type Female, Right Angle

Current Rating 1.8A max
Insulation Resistance 1000 M min at 500V DC
LED Indicator No
Contact Resistance 30 m max
Compliance RoHS Compliant
Standard USB 3.0 SuperSpeed
Contact Plating Gold over Nickel
Cover/Cap Included No
Dielectric Withstanding Voltage 750V AC/minute
Number of Pins 9
Mating Cycles 1500 cycles minimum
Mounting Style Right Angle, Through Hole, PCB Mount

Product Description

Unlock the potential of high-speed connectivity with the redoubtable USB A TYPE FEMALE RA PCB 9 Pin Version 3.0. Explore magnificent data transfer at USB 3.0 SuperSpeed, supported by valuable features such as a right-angle through-hole design for streamlined PCB mounting. Gold over nickel plating enhances contact reliability, while robust material construction ensures longevity and flame resistance (UL94V-0). Highlighted by a 1.8A current rating, 1500+ mating cycles, and RoHS compliance, this connector stands as a powerful choice for manufacturers, traders, importers, and distributors seeking superior connectivity solutions.

Optimized Application, Media, and Versatile Usage

Highlighted for its magnificence in USB 3.0 high-speed data transfer, this connector is perfect for electronic PCBs, embedded systems, and communication infrastructure. Equipped for both consumer and industrial environments, its valuable right-angle design streamlines installation and supports robust devices. Suitable for use in computers, routers, motherboards, and other high-performance applications, it enhances connectivity and reliability for any enterprise or individual seeking advanced data solutions.

Reliable Supply, Packaging, and Sample Solutions

Our supply process is optimized for low expenditure and maximum efficiency. Detailed quotations are available for bulk orders, and products are securely packaged for safe transit. Samples can be dispatched upon a formal request, adhering to our customer-friendly sample policy, ensuring you evaluate compatibility before making major procurement decisions. Our streamlined ordering and delivery system guarantees satisfaction and prompt support for all importers, exporters, and wholesale buyers across India.

FAQ's of USB A TYPE FEMALE RA PCB 9 Pin Version 3.0:

Q: How is the USB A TYPE FEMALE 9 Pin connector mounted to a PCB?

A: This connector features a right-angle, through-hole design, enabling secure and efficient mounting directly onto a printed circuit board for stable and reliable connections.

Q: What types of devices benefit from using this USB 3.0 connector?

A: Devices such as computers, routers, industrial control systems, and PCBs that require high-speed data transfer and robust PCB mounting benefit greatly from this advanced connector.

Q: Where can I obtain quotations for bulk or wholesale orders?

A: Quotations for bulk or wholesale orders can be requested directly from distributors, exporters, or manufacturers in India, who will provide the necessary pricing and lead time details.

Q: When can sample units be dispatched upon request?

A: Sample units are typically dispatched promptly after receiving a formal sample request as per the company's sample policy, enabling thorough evaluation before procurement.

Q: What makes this connector valuable for industrial applications?

A: Its high current rating, flame resistance (UL94V-0), and robust construction with gold-plated contacts and a metal shield make it both resilient and reliable in demanding industrial environments.

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number

Other Products in 'USB and Micro Jack Connector' category

USB A TYPE FEMALE DUAL RA PCB 3.0 Price : 175 INR/Piece Minimum Order Quantity : 100 Connector Type : Other, USB 3.0 Dual Right Angle, PCB Mount Application : PCB Mounting, USB 3.0 Data and Power Transfer Connector : USBA Type Female Dual Port Right Angle Color : Other, Blue (Plastic Core), Silver (Shell) Material : Other , Copper Alloy (Contact), Stainless Steel (Shield), Thermoplastic (Housing) Cable Type : other, N/A (Connector only) Number of Conductor : N/A (for connector only) Voltage Rating : 30V AC (Max) Insulation : HighTemperature Thermoplastic UL94V0 Sheild : Yes, with full metal shell for EMI/RFI protection Female End Type : USBA Type Female Dual Port Flame Resistance Level : UL94V0 Temperature : 40C to +85C Operating Range Capacity : Supports USB 3.0 HighSpeed Data Transfer (up to 5Gbps) Wire Gauge : N/A (for connector only) Outer Diameter : N/A (for connector only) Length : N/A (PCB Mount) Jacket Material : Other, N/A (for connector only) Cable Length : N/A (for connector only) Pairs : N/A (for connector only)
