YA20 250V 5A 9Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal

Name: YA20 250V 5A 9Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 460.0 INR
Availability: InStock

460.0 INR/Piece

Get a Price/Quote

Product Details:

Power Source External supply
Components Metal shell, solder terminals, rubber waterproof rings, 9-pin female insert
IP Rating IP67
Output PCB or device interface
Power Supply AC
Usage Panel mount for power and signal connection
Input 9-pin female socket
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YA20 250V 5A 9Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 460.0 INR/Piece

Wiring Method Solder termination
Connector Gender Female
Vibration Resistance Compliant with IEC 60512-6-4 standard
Contact Resistance 5m
Mechanical Lifespan > 500 mating cycles
Sealing Method Rubber O-ring gasket
Contact Material Copper alloy with gold or nickel plating
Number of Pins 9
Locking Mechanism Threaded locking ring for secure mating
Shell Material Zinc alloy (nickel-plated)
Mounting Hole Diameter Approx. 22mm
Withstanding Voltage 1500V AC/minute
Flame Resistance UL94-V0 rated insulating material
Insulation Resistance > 500M at 500V DC

YA20 250V 5A 9Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Product Specifications

Frequency 50/60Hz
Dimension (L*W*H) Approx. 47.5mm (length, with locking ring) x 29.5mm (diameter)
Rated Voltage 250V
Size YA20 size series
Product Type Waterproof power connector, panel mount type
Input 9-pin female socket
Capacity 5A per contact
Interface 9-pin circular power/signal interface
Operating Temperature -40C to +85C
Features IP67 waterproof, metal shell, panel mount, solder pin, corrosion resistant
Current Rating 5A
Function Power connection in industrial and outdoor environments
IP Rating IP67
Components Metal shell, solder terminals, rubber waterproof rings, 9-pin female insert
Power Source External supply
Output PCB or device interface
Power Supply AC
Usage Panel mount for power and signal connection
Application Industrial automation, power distribution, machinery, instrumentation
Color Silver
Supply Voltage 250V AC
Weight Approx. 63g

Wiring Method Solder termination
Connector Gender Female
Vibration Resistance Compliant with IEC 60512-6-4 standard
Contact Resistance 5m
Mechanical Lifespan > 500 mating cycles
Sealing Method Rubber O-ring gasket
Contact Material Copper alloy with gold or nickel plating
Number of Pins 9
Locking Mechanism Threaded locking ring for secure mating
Shell Material Zinc alloy (nickel-plated)
Mounting Hole Diameter Approx. 22mm
Withstanding Voltage 1500V AC/minute
Flame Resistance UL94-V0 rated insulating material
Insulation Resistance > 500M at 500V DC

YA20 250V 5A 9Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:250V
Withstanding voltage:1500V
Contact dimension:Phi 1x9
Insertion and extraction force:2.7N Max
Mating cycle:1700 Times
Temperature and humidity:-40+80C; 40C, 85%RH
Screw torque:42-53 (N.m)

Durable Waterproof Construction

Engineered with a nickel-plated zinc alloy shell and sealed by a rubber O-ring gasket, the YA20 socket achieves IP67 waterproof protection. Its design prevents dust ingress and withstands high-pressure water jets, ensuring uninterrupted operation even in harsh outdoor environments, industrial settings, or areas susceptible to moisture exposure. This robust sealing extends the device's lifespan and reliability where environmental protection is critical.

Secure Power and Signal Connectivity

With a 9-pin female circular interface and threaded locking ring, this connector guarantees a secure, vibration-resistant connection for both power and signal transmission. The copper alloy contacts, with gold or nickel plating, offer excellent conductivity and minimal contact resistance, enhancing safety and consistent power delivery in industries such as automation and power distribution.

Easy Panel Mount Installation

Designed for panel mounting, the YA20 socket requires only a 22mm mounting hole and offers straightforward solder termination. The solid metal build and clear interface simplify installation into machinery or distribution boxes, ensuring rapid deployment in control panels or automation equipment without sacrificing durability or integrity.

FAQ's of YA20 250V 5A 9Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal:

Q: How should the YA20 9Pin Female Socket be installed in a panel?

A: The YA20 socket is designed for panel mount installation. Drill a mounting hole of approximately 22mm diameter, insert the connector from the front, and secure it with the threaded locking ring. Connections to the device or PCB are made through solder termination on the rear pins.

Q: What environments are best suited for using this power connector?

A: This socket is ideal for harsh, industrial, and outdoor environments requiring secure power and signal connections. Its IP67-rated waterproof and vibration-resistant features make it suitable for automation systems, power distribution panels, machinery, and instrumentation used in challenging locations.

Q: When is an IP67 waterproof connector necessary?

A: You should use an IP67 waterproof connector whenever equipment is exposed to dust, water splashes, rain, or temporary submersion. The YA20 connector safeguards connections from environmental damage, helping maintain continuous operation in critical applications.

Q: Where does the YA20 socket connect within a system?

A: This female socket is mounted onto control panels, machinery enclosures, or junction boxes. The nine solder pins interface with internal system wiring, allowing connection to external devices or cables fitted with a compatible 9-pin male plug.

Q: What is the benefit of the threaded locking mechanism?

A: The threaded locking ring secures the mating connector, preventing accidental disconnection and ensuring a stable electrical connection. This is vital where vibration or external forces might cause plug disengagement in industrial machinery or outdoor equipment.

Q: How is long-term durability achieved with this connector?

A: The YA20's metal shell, robust insulation, and quality plating offer resistance to corrosion, high temperatures, and repeated use-tested for over 500 mating cycles. Its compliance with IEC 60512-6-4 vibration resistance standard further extends service life in demanding conditions.
