YU Series USB3.0 Female-Male IP67 Waterproof Data Connector 1M Cable

Name: YU Series USB3.0 Female-Male IP67 Waterproof Data Connector 1M Cable
Brand: CONNECTOR DEVICES
Price: 950 INR
Availability: InStock

950 INR/Piece

Get a Price/Quote

Product Details:

Usage Outdoor/industrial data transfer applications
Input USB3.0 Male
Power Source USB
Interface USB3.0 Type A Female to Male
Operating Temperature -20C to +60C
Charging Voltage 5V
Features Waterproof, dustproof, corrosion resistant, plug and play
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YU Series USB3.0 Female-Male IP67 Waterproof Data Connector 1M Cable Price And Quantity

Minimum Order Quantity 100 Piece
Price 950 INR/Piece

YU Series USB3.0 Female-Male IP67 Waterproof Data Connector 1M Cable Product Specifications

Dimension (L*W*H) Cable length 1m, connector size 23mm diameter x 55mm length (each side)
Size 1 Meter Cable Length
Power Source USB
Supply Voltage 5V
Input USB3.0 Male
Usage Outdoor/industrial data transfer applications
Weight Approx. 85g
Current Rating Up to 1.8A
Color Black
Product Type USB3.0 Waterproof Data Connector Cable
Rated Voltage 5V DC
IP Rating IP67
Power Supply USB powered
Function High-speed data transmission and waterproof USB connectivity
Features Waterproof, dustproof, corrosion resistant, plug and play
Charging Voltage 5V
Components USB3.0 Female and Male Connectors, cable, waterproof housing
Output USB3.0 Female
Thickness Standard cable diameter ~5mm
Capacity Supports up to 5Gbps data transfer
Interface USB3.0 Type A Female to Male
Application Industrial, Marine, Outdoor Equipment, Harsh Environments
Operating Temperature -20C to +60C

Compliance RoHS, CE certified
Cable Material Oxygen-free copper with PVC insulation
Waterproof Seal Type Integrated rubber gasket
Compatibility Backward compatible with USB2.0/1.1 devices
Insulation Resistance 100M at 500V DC
Contact Resistance 30m
Shielding Double shielded for enhanced EMI/RFI protection
Mounting Type Panel mount capability on female end
Connector Material Gold-plated pins, nickel-plated shell

Product Description

Brand:CNLINKO
Connection Mode:Quick bayonet connection
Rated Current:1.5A
Protection Level:IP67
Mating Cycle:>500 cycles
Cable Length:1 Meter
Working Temperature:-40~80C

Superior Waterproof Protection

Rated at IP67, this USB3.0 connector cable offers complete protection against dust and can withstand immersion in water up to 1 meter, making it a dependable choice for outdoor, industrial, and marine applications. The integrated rubber gasket forms a secure seal, ensuring uninterrupted performance even in harsh, wet environments.

Engineered for High-Speed, Reliable Data Transfer

With its oxygen-free copper material and double shielding, the cable minimizes interference and provides stable data transfer rates up to 5Gbps. The gold-plated pins and nickel-plated shell further enhance signal integrity and durability, making it perfect for mission-critical data transmission tasks.

Easy, Versatile Installation and Usage

Designed with a panel-mount female end and a plug-and-play approach, the YU Series connector caters to installers and end-users alike. Its compatibility with USB2.0/1.1 devices, backward compatibility, and standard 1-meter length make it adaptable for a wide array of setups. Suitable for use by distributors, exporters, manufacturers, and traders in India.

FAQ's of YU Series USB3.0 Female-Male IP67 Waterproof Data Connector 1M Cable:

Q: How does the YU Series USB3.0 cable provide waterproof connectivity?

A: The cable features an integrated rubber gasket and a nickel-plated shell, ensuring an IP67 rating for complete protection against dust and immersion in up to 1 meter of water. This design enables secure and waterproof data and power connections in challenging environments.

Q: What benefits does the double-shielded design offer?

A: Double shielding significantly reduces electromagnetic and radio frequency interference (EMI/RFI), ensuring cleaner, more stable data transmission and reliable high-speed performance even in areas with heavy electrical noise.

Q: Where can this USB connector be used?

A: It's ideal for industrial, marine, outdoor equipment, and harsh environments where robust, waterproof, and dustproof USB connectivity is essential. Its panel mount capability on the female end allows secure installation in control panels or equipment housings.

Q: What is the process for installing the panel mount female connector?

A: The female end of the cable is designed for panel mounting and can be securely fastened using the integrated threads. This provides stable installation in equipment enclosures or panels, ensuring a lasting and protected connection.

Q: What compatibility should I expect with other USB devices?

A: This connector supports USB3.0 and is backward compatible with USB2.0 and USB1.1 standards. You can use it with a wide range of USB devices supporting 5V DC power, ensuring flexibility and broad usability.

Q: When should I choose this connector over standard USB cables?

A: Select the YU Series IP67 connector when you require reliable, waterproof performance, high-speed data transfer up to 5Gbps, and protection against dust or corrosion in industrial, marine, or outdoor settings.
