YM20 5A 12Pin Male Plug IP68 Waterproof Power Connector Plastic Shell Solder Terminal

Name: YM20 5A 12Pin Male Plug IP68 Waterproof Power Connector Plastic Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 374.0 INR
Availability: InStock

374.0 INR/Piece

Get a Price/Quote

Product Details:

Input Solder Terminal
Operating Temperature -25C~+85C
Output Solder Terminal
Components Male Plug, Solder Contacts, Plastic Shell
IP Rating IP68
Interface Solder Terminal, 12Pin
Power Source Electrical
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YM20 5A 12Pin Male Plug IP68 Waterproof Power Connector Plastic Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 374.0 INR/Piece

Coupling Method Threaded Lock
Flammability Rating UL94V-0
Shell Material Nylon Plastic (PA66)
Number of Pins 12
Wire Gauge Support 16-20 AWG
Connection Type Panel Mount Male Plug
Cable Range 6-12mm
Contact Resistance 2.5m
Insulation Resistance >2000M
Mechanical Life >500 Mating Cycles
Withstand Voltage 1500V AC/minute
Contact Material Copper Alloy, Gold-plated

YM20 5A 12Pin Male Plug IP68 Waterproof Power Connector Plastic Shell Solder Terminal Product Specifications

IP Rating IP68
Interface Solder Terminal, 12Pin
Supply Voltage 250V AC/DC
Components Male Plug, Solder Contacts, Plastic Shell
Usage Outdoor Power Connection
Rated Voltage 500V AC
Thickness Standard
Power Supply Wire Connection
Output Solder Terminal
Function Power and Signal Transmission
Features Waterproof, Dustproof, Durable, Corrosion-resistant
Product Type Male Plug Connector
Size YM20
Operating Temperature -25C~+85C
Capacity 5A per Pin
Dimension (L*W*H) 79mm (Length)
Color Black
Application LED Lighting, Outdoor Equipment, Industrial Power
Weight Approx. 45g
Current Rating 5A
Power Source Electrical
Input Solder Terminal
Frequency 50/60Hz

Coupling Method Threaded Lock
Flammability Rating UL94V-0
Shell Material Nylon Plastic (PA66)
Number of Pins 12
Wire Gauge Support 16-20 AWG
Connection Type Panel Mount Male Plug
Cable Range 6-12mm
Contact Resistance 2.5m
Insulation Resistance >2000M
Mechanical Life >500 Mating Cycles
Withstand Voltage 1500V AC/minute
Contact Material Copper Alloy, Gold-plated

YM20 5A 12Pin Male Plug IP68 Waterproof Power Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:250V
Withstanding voltage:2500V
Insertion and extraction force:4.0N Max
Screw torque:42-53 (N.m)
Temperature and humidity:-4080C; 40C, 85%RH
Contact dimension:Phi 2.7*2

Superior Durability and Waterproof Design

Engineered to meet IP68 standards, the YM20 connector is built to withstand harsh outdoor environments, resisting water, dust, and corrosion. The nylon plastic (PA66) shell and gold-plated copper alloy contacts extend the lifespan of the device, ensuring that it operates reliably in extreme conditions ranging from -25C to +85C. Its sturdy build and UL94V-0 flammability rating make it a safe and durable choice.

Versatile and Secure Application

Featuring a panel mount male plug and a threaded lock coupling, the YM20 provides strong, vibration-resistant fastening in installations. Suitable for wires ranging from 16-20 AWG and supporting up to 5A per pin, it accommodates different power and signal requirements in LED lighting, outdoor gear, and industrial power systems. The solder terminal interface enables straightforward, secure wire connections.

Exceptional Electrical Performance

With a rated voltage of 500V AC and a high insulation resistance exceeding 2000M, the YM20 male plug maintains stability and prevents leakage in demanding electrical setups. The connector's gold-plated contacts reduce resistance and maximize current flow, supporting up to 500 mating cycles to minimize maintenance and replacement frequency.

FAQ's of YM20 5A 12Pin Male Plug IP68 Waterproof Power Connector Plastic Shell Solder Terminal:

Q: How do I install the YM20 5A 12Pin Male Plug in my outdoor power system?

A: To install the YM20 plug, pass your 6-12mm cable through the shell, solder your 16-20 AWG wires to the contacts, and secure the connector to your panel using the threaded lock. Ensure the waterproof seals are correctly in place before tightening.

Q: What applications are best suited for this connector?

A: This connector is ideal for outdoor power connections involving LED lighting, industrial equipment, and any scenario requiring reliable power and signal transmission in harsh or wet environments.

Q: When is the YM20 12Pin connector recommended over other plug types?

A: Choose the YM20 connector when you need a combination of high waterproof rating (IP68), durability, multiple signal/power pins, and stable connection in demanding outdoor or industrial conditions.

Q: Where can I use this connector given its IP68 rating?

A: Its IP68-rated design ensures suitability for outdoor installations exposed to rain, dust, and even temporary immersion in water, making it perfect for exposed locations and industrial sites.

Q: What are the benefits of the gold-plated copper alloy contacts?

A: Gold plating enhances electrical conductivity, reduces contact resistance, and prevents oxidation or corrosion, ensuring reliable connection over many cycles and adverse conditions.

Q: How durable is the connector for frequent operations?

A: The YM20 plug exceeds 500 mating cycles thanks to its robust build and quality materials, making it highly reliable for long-term use in both fixed and portable equipment.

Q: What safety features does the YM20 male plug offer?

A: It includes a flame-retardant shell (rated UL94V-0), high insulation resistance, and a secure threaded lock, protecting against electrical hazards, sparks, and accidental disconnection.
