YT RJ45 Cat6A Female Socket Waterproof Ethernet Connector IP67 Panel Mount PCB Shield

Name: YT RJ45 Cat6A Female Socket Waterproof Ethernet Connector IP67 Panel Mount PCB Shield
Brand: CONNECTOR DEVICES
Price: 292.0 INR
Availability: InStock

292.0 INR/Piece

Get a Price/Quote

Product Details:

Usage Panel Mount Ethernet Connection
Components RJ45 Cat6A Female Socket, Panel Mount Shield, PCB Pins, Waterproof Gasket
IP Rating IP67
Output PCB Mount Pins
Features Shielded, Dustproof, Waterproof, Corrosion Resistant, Quick Panel Mount
Operating Temperature -40C to +85C
Input RJ45 Female Socket
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YT RJ45 Cat6A Female Socket Waterproof Ethernet Connector IP67 Panel Mount PCB Shield Price And Quantity

Minimum Order Quantity 100 Piece
Price 292.0 INR/Piece

Shielding Full Metal Shielded
Compatible Cable Type Cat5e/Cat6/Cat6A
Flammability Rating UL94V-0
Durability >750 Mating Cycles
Material Metal shield with high-quality plastic insulator
Environmental Protection Outdoor Use, UV and Humidity Resistant
Connector Gender Female to PCB Pin
Contact Resistance <30m
Insulation Resistance >500M @ 500V DC
Mounting Type Panel Mount, PCB Through Hole
Mating Connector Standard 8P8C RJ45 Plug
Standards Supported Category 6A (Cat6A), ANSI/TIA-568-C.2
Sealing Method O-Ring Seal/Gasket
RoHS Compliant Yes

YT RJ45 Cat6A Female Socket Waterproof Ethernet Connector IP67 Panel Mount PCB Shield Product Specifications

Interface RJ45, PCB Mount
Product Type Waterproof Ethernet Connector
Capacity 10Gbps Data Transfer Rate
Input RJ45 Female Socket
Operating Temperature -40C to +85C
Output PCB Mount Pins
Features Shielded, Dustproof, Waterproof, Corrosion Resistant, Quick Panel Mount
Current Rating 1.5A Max
Components RJ45 Cat6A Female Socket, Panel Mount Shield, PCB Pins, Waterproof Gasket
IP Rating IP67
Function Ethernet Data Transmission
Application Outdoor/Industrial Data Networking
Size Standard Cat6A RJ45 Socket Size
Rated Voltage DC 50V
Usage Panel Mount Ethernet Connection
Dimension (L*W*H) 35.5 mm x 26 mm x 25 mm (Approx.)
Weight Approximately 20g
Frequency Up to 500 MHz
Color Black

Shielding Full Metal Shielded
Compatible Cable Type Cat5e/Cat6/Cat6A
Flammability Rating UL94V-0
Durability >750 Mating Cycles
Material Metal shield with high-quality plastic insulator
Environmental Protection Outdoor Use, UV and Humidity Resistant
Connector Gender Female to PCB Pin
Contact Resistance <30m
Insulation Resistance >500M @ 500V DC
Mounting Type Panel Mount, PCB Through Hole
Mating Connector Standard 8P8C RJ45 Plug
Standards Supported Category 6A (Cat6A), ANSI/TIA-568-C.2
Sealing Method O-Ring Seal/Gasket
RoHS Compliant Yes

YT RJ45 Cat6A Female Socket Waterproof Ethernet Connector IP67 Panel Mount PCB Shield Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting Mode:1/4 bayonet connecting type
Cable Specification:0.15mm2 0.2mm2 /2624AWG
Diameter Range:5.5mm 7mm
Operating Voltage(AC.V.rms):42V
Withstand Voltage(AC.V)1min:1000V
Durability:>500 mating & unmating cycles
Temperature Rating:-4080C

Superior Environmental Protection

This connector is designed for outdoor and industrial environments, featuring IP67 waterproofing, UV resistance, and full protection against dust and humidity. The robust metal shield and O-ring seal safeguard data transmission and assure reliable performance in challenging conditions.

High-Speed Secure Data Transmission

Supporting Cat6A cables and operating at up to 500 MHz, the connector delivers reliable 10Gbps data transfer rates. Its full metal shield and secure PCB pin interface enhance signal integrity, prevent interference, and meet ANSI/TIA-568-C.2 standards.

Effortless Panel Mount and Durability

Designed for quick panel mounting, this connector supports over 750 mating cycles, ensuring long-term stability and minimal maintenance. The UL94V-0 flammability rating and RoHS compliance underline its safety and durability for demanding applications.

FAQ's of YT RJ45 Cat6A Female Socket Waterproof Ethernet Connector IP67 Panel Mount PCB Shield:

Q: How is the YT RJ45 Cat6A Female Socket installed in a panel?

A: This connector is designed for straightforward panel mounting using its standard dimensions. The PCB through-hole interface allows secure attachment to printed circuit boards, while the O-ring or gasket ensures a waterproof and dustproof seal on the panel surface.

Q: What environments is this Ethernet connector suitable for?

A: With its IP67 rating and UV, humidity, and corrosion resistance, this connector is ideal for outdoor, industrial, and harsh environments such as networking for factories, outdoor equipment, and exposed data panels.

Q: When should I use a shielded waterproof RJ45 socket like this one?

A: Choose this connector when you require high-speed Ethernet connections (up to 10Gbps) in environments prone to moisture, dust, or electromagnetic interference. Its robust design ensures uninterrupted data transmission even in challenging conditions.

Q: What type of Ethernet cables are compatible with this connector?

A: The connector supports Cat5e, Cat6, and Cat6A cables, making it versatile for multiple networking standards up to Category 6A with 10Gbps speeds.

Q: How does the IP67 rating benefit the installation process?

A: The IP67 rating means the connector is fully protected against dust ingress and can withstand immersion in water up to 1 meter deep. This ensures reliable and safe installations outdoors and in damp or dusty locations.

Q: Where can I source this connector in India?

A: This product is available through distributors, exporters, importers, manufacturers, traders, and wholesalers specializing in networking components across India.

Q: What is the benefit of the full metal shielding and UL94V-0 flammability rating?

A: The full metal shielding guards against electromagnetic interference, maintaining network performance, while the UL94V-0 flammability rating ensures the connector's materials meet strict fire safety standards-ideal for industrial and mission-critical applications.
