YT-RJ45 Series RJ45 Male Plug IP65 Waterproof Ethernet Connector

Name: YT-RJ45 Series RJ45 Male Plug IP65 Waterproof Ethernet Connector
Brand: CONNECTOR DEVICES
Price: 241.0 INR
Availability: InStock

241.0 INR/Piece

Get a Price/Quote

Product Details:

Usage Outdoor/Industrial Network Connections
Input RJ45 Male Plug
Output RJ45 Connection
Components Plug, Waterproof Cap, Gasket
Power Supply Passive, via Ethernet
Interface RJ45 Male Plug
IP Rating IP65
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YT-RJ45 Series RJ45 Male Plug IP65 Waterproof Ethernet Connector Price And Quantity

Price 241.0 INR/Piece
Minimum Order Quantity 100 Piece

Material PA66 (Nylon), flame retardant
Number of Pins 8P8C (8 positions, 8 contacts)
Mounting Type Panel mount or inline
Compliance Standards RoHS, CE
Cable Diameter Supported 6~8mm
Mating Cycles >500 times
Sealing Silicone gasket included
Contact Material Gold-plated Contacts
Shielding Shielded for EMI/RFI protection
Locking Mechanism Screw/Latch Lock

YT-RJ45 Series RJ45 Male Plug IP65 Waterproof Ethernet Connector Product Specifications

Size M19 Threaded Body
Application Ethernet communication in harsh environments, outdoor devices, communications cabinet, control panels
Power Supply Passive, via Ethernet
Current Rating 1.5A max
Dimension (L*W*H) 80mm x 19mm x 19mm (including cap)
Output RJ45 Connection
Components Plug, Waterproof Cap, Gasket
Supply Voltage Up to 48V DC
Function Ethernet Data Transmission and Waterproof Protection
Input RJ45 Male Plug
Thickness Standard, 19mm housing diameter
Rated Voltage DC 48V max
Features IP65 waterproof, dustproof, UV-resistant, corrosion-resistant, quick installation
Operating Temperature -20C to +80C
Interface RJ45 Male Plug
Product Type RJ45 Male Plug IP65 Connector
Capacity Supports 1000Base-T (Gigabit Ethernet)
Weight Approx. 28g
Frequency Ethernet 10/100/1000 Mbps
Color Black
IP Rating IP65
Usage Outdoor/Industrial Network Connections

Material PA66 (Nylon), flame retardant
Number of Pins 8P8C (8 positions, 8 contacts)
Mounting Type Panel mount or inline
Compliance Standards RoHS, CE
Cable Diameter Supported 6~8mm
Mating Cycles >500 times
Sealing Silicone gasket included
Contact Material Gold-plated Contacts
Shielding Shielded for EMI/RFI protection
Locking Mechanism Screw/Latch Lock

YT-RJ45 Series RJ45 Male Plug IP65 Waterproof Ethernet Connector Trade Information

Delivery Time 7 Days

Product Description

Discover top-notch performance with the YT-RJ45 Series RJ45 Male Plug IP65 Waterproof Ethernet Connector, expertly crafted for robust outdoor and industrial network solutions. Personalise your Ethernet setup with this noble connector equipped with gold-plated contacts for lustrous conductivity and shielded for superior EMI/RFI protection. The flame-retardant PA66 body ensures enhanced safety, while the innovative screw/latch locking mechanism guarantees a secure fit. Order with confidence, knowing you're investing in a connector built for endurance, compliant with RoHS and CE standards, offering over 500 reliable mating cycles. Markdown your maintenance concerns with its silicone gasket, delivering exceptional waterproof sealing.

Commercial Utility & Application Features

The YT-RJ45 Series excels in demanding commercial environments such as outdoor devices, communication cabinets, and control panels. Engineered for straightforward installation via panel mount or inline application, it features quick connectivity and sealing for Ethernet data transmission. Its IP65 waterproof and dustproof rating ensures resilience during rigorous field use, while gold-plated contacts and screw/latch locking contribute to stable, long-term networking performance across varied industrial applications.

Terms, Supply, and Export Information

Flexible payment terms make it simple to order your YT-RJ45 Series connectors. We supply bulk shipments with prompt delivery, ensuring rapid arrival for urgent projects. With competitive list prices and consistent stock for exporters in India and international markets, your needs are covered. Expect standard delivery times subject to shipping location, supporting seamless integration into your supply chain for global commercial deployment.

FAQ's of YT-RJ45 Series RJ45 Male Plug IP65 Waterproof Ethernet Connector:

Q: How does the YT-RJ45 Series ensure protection in harsh environments?

A: The connector is built with an IP65 waterproof and dustproof design, shielded for EMI/RFI, corrosion-resistant materials, and a silicone gasket for superior sealing, supporting stable operation even in challenging outdoor and industrial settings.

Q: What are the main applications of this Ethernet connector?

A: This connector is ideal for Ethernet communication in outdoor devices, communications cabinets, control panels, and anywhere robust, waterproof networking connections are required, especially in harsh operating environments.

Q: Where can the YT-RJ45 Series RJ45 Male Plug be installed?

A: The connector is designed for versatile use, allowing for both panel mount and inline installation to accommodate a variety of network layouts and equipment requirements.

Q: What benefits do gold-plated contacts provide in this product?

A: Gold-plated contacts deliver lustrous conductivity, ensuring reliable Ethernet data transfer by reducing signal loss and preventing corrosion over extended use.

Q: How many mating cycles can the connector withstand?

A: The YT-RJ45 Series is rated for over 500 mating cycles, offering durability and longevity for repeated network connection and disconnection.
