YU Series USB3.0 Female-Male IP67 Waterproof Data Connector

713.0 INR/Piece

Get a Price/Quote

Product Details:

IP Rating IP67
Components Connector, sealing nut, washer, dust cap
Power Supply USB Bus-powered
Input USB 3.0 Male
Output USB 3.0 Female
Operating Temperature -40C to +85C
Charging Voltage 5V DC
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YU Series USB3.0 Female-Male IP67 Waterproof Data Connector Price And Quantity

Minimum Order Quantity 100 Piece
Price 713.0 INR/Piece

YU Series USB3.0 Female-Male IP67 Waterproof Data Connector Product Specifications

Color Black
Supply Voltage 5V DC
Capacity Supports up to 5Gbps data transfer
Power Supply USB Bus-powered
Function Data transmission and waterproof protection
Input USB 3.0 Male
Thickness Standard Connector Thickness
Components Connector, sealing nut, washer, dust cap
IP Rating IP67
Current Rating 1.8A Max
Weight 35g
Operating Temperature -40C to +85C
Output USB 3.0 Female
Product Type USB 3.0 Waterproof Data Connector
Features Dustproof, waterproof, corrosion-resistant, high-speed data transfer
Charging Voltage 5V DC
Power Source USB-powered
Interface USB 3.0 Female to Male
Dimension (L*W*H) 62mm x 25mm x 20mm
Usage Outdoor and industrial USB connection
Application Industrial, outdoor communication, marine, equipment interfaces
Size Standard USB 3.0
Rated Voltage 250V AC Max

Material High-grade plastic and nickel-plated contacts
Insulation Resistance >1000M @ 500V DC
Cable Length Customizable (typically supplied without cable)
Compatible Standards USB 2.0/3.0/3.1
Mating Cycle Durability 1500 cycles
Contact Resistance 30m
Flammability Rating UL94V-0
Sealing Type Screw locking with O-ring rubber gasket
Mounting Type Panel mount

YU Series USB3.0 Female-Male IP67 Waterproof Data Connector Trade Information

Delivery Time 7 Days

Product Description

Take advantage of our splendid Promotion and buy the YU Series USB3.0 Female-Male IP67 Waterproof Data Connector during this breathtaking Clearance offer! Crafted with high-grade plastic and nickel-plated contacts, this sublime panel-mount connector offers unparalleled data transmission speeds up to 5Gbps and robust waterproof protection. The plug's precision-engineered screw-locking design with an O-ring gasket guarantees an IP67 seal, perfect for outdoor and industrial environments. Rated for 1.8A max current, UL94V-0 flammability, and up to 1500 mating cycles, it excels in mission-critical marine, communication, and equipment interfaces. Distributor and exporter in India, supporting USB 2.0/3.0/3.1 standards.

Versatile Performance for Rugged Use

The YU Series USB3.0 Female-Male IP67 Waterproof Data Connector is meticulously designed for demanding outdoor environments, industrial automation, marine electronics, and equipment interfaces. Boasting sublime waterproof and dustproof sealing, it ensures reliable operation even in harsh conditions. Its panel mount and standardized dimensions make installation effortless, delivering steadfast connections and rapid data exchange. The connector is corrosion-resistant and supports USB 2.0, 3.0, and 3.1, making it ideal for a wide range of high-speed data transmission applications.

Hassle-Free Payment, Secure Delivery & Samples

We offer flexible payment terms for the YU Series USB3.0 Data Connector, accommodating various customer needs. Packing & Dispatch services are optimized to ensure your goods transport journey is seamless and secure. Our goods are dispatched from major FOB Ports in India, ensuring timely and safe delivery. Sample policy is transparent-customers can request product samples for evaluation. Each piece is carefully packed to maintain product quality during transit and arrives ready for installation.

FAQ's of YU Series USB3.0 Female-Male IP67 Waterproof Data Connector:

Q: How does the YU Series USB3.0 connector ensure waterproof and dustproof protection?

A: The connector features a screw locking design with an O-ring rubber gasket, and the overall construction meets the IP67 rating, offering robust dustproof and waterproof sealing for outdoor and industrial use.

Q: What specific applications can benefit from using this data connector?

A: It is ideal for outdoor communication systems, marine electronics, industrial automation, and any application requiring reliable, high-speed USB connections in challenging environments.

Q: Where should I install this connector for optimal performance?

A: This panel mount connector is best installed on equipment interfaces, control panels, or enclosures where exposure to moisture, dust, or mechanical stress is likely.

Q: What is the process for customizing the cable length?

A: The connector is typically supplied without a cable, but customers can specify custom cable lengths during ordering. Consult with your distributor or manufacturer for tailored configurations.

Q: What are the main benefits of using nickel-plated contacts and high-grade plastic in this connector?

A: Nickel-plated contacts deliver excellent conductivity and corrosion resistance, while the high-grade plastic housing ensures long-term durability and protection against harsh environmental factors.

Q: How is the connector packed and dispatched for safe transport?

A: Each connector is thoroughly packed to prevent damage during transit, and dispatched through reliable logistics from Indian FOB ports, ensuring the product arrives in optimal condition.
