DH20 500V 20A 3Pin Male Plug IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal

776.0 INR/Piece

Get a Price/Quote

Product Details:

Features Metal Shell, Waterproof, Dustproof, Solder Terminals, Anti-corrosion
Usage Electrical Power Distribution
IP Rating IP67
Power Supply AC/DC Compatible
Output Cable Termination (Solder Terminal)
Operating Temperature -40C to +80C
Power Source Wired Power
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

DH20 500V 20A 3Pin Male Plug IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Price And Quantity

Price 776.0 INR/Piece
Minimum Order Quantity 100 Piece

DH20 500V 20A 3Pin Male Plug IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Product Specifications

Product Type Waterproof Power Connector
Supply Voltage 500V AC/DC
Power Supply AC/DC Compatible
Current Rating 20A
Capacity 20A Current Carrying
Weight Approx. 180g
IP Rating IP67
Dimension (L*W*H) Approx. 90mm (Length) x 33mm (Diameter)
Input 3 Pin Male Connector
Components Plug body, pins, locking ring, sealing ring
Interface 3 Pin Solder Terminal
Size DH20 Shell Size
Function Power Connection
Rated Voltage 500V
Features Metal Shell, Waterproof, Dustproof, Solder Terminals, Anti-corrosion
Thickness Shell Approx. 2mm
Power Source Wired Power
Usage Electrical Power Distribution
Color Silver (Metallic)
Application Industrial Equipment, Outdoor Power, Machinery, Marine, Automation
Operating Temperature -40C to +80C
Output Cable Termination (Solder Terminal)
Frequency 50/60Hz

Mechanical Life 500 Mating Cycles
Cable Entry Rear Cable Clamp
Contact Resistance 2m
Sealing Method Rubber Washer and Grommet
Connection Mode Solder Connection
Insulation Resistance >2000 M at 500V DC
Mounting Type Inline Free Plug
Shell Material Zinc Alloy with Electroplated Surface
Locking System Threaded Coupling Ring
Cable Diameter Range 8mm to 12mm
Environmental Protection UV Resistant, Vibration Resistant
Withstanding Voltage 1500V AC for 1 Minute
Contact Material Copper Alloy, Silver-Plated Contacts
Standards Compliance CE, RoHS
Pin Configuration 3 Pin Male
Flammability Rating UL94 V-0

DH20 500V 20A 3Pin Male Plug IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Experience the finest quality with the DH20 500V 20A 3Pin Male Plug IP67 Metal Waterproof Power Connector-crafted with a preeminent zinc alloy shell and silver-plated copper contacts for optimal conductivity. This dominant, top-rated power connector guarantees safety and reliability even in the harshest environments, boasting IP67 waterproof and dustproof protection. Designed for industrial strength and versatility, it supports both AC and DC power at a substantial 20A capacity. Grab this limited stock at a discount rate-ideal for automation, marine, or outdoor setups demanding the utmost performance and longevity.

Versatile Applications and Key Advantages

The DH20 500V 20A 3Pin Male Plug IP67 excels across industrial equipment, outdoor power systems, machinery, marine applications, and automation lines. Its robust electroplated zinc alloy surface ensures durability and resistance to corrosion, while the IP67 rating delivers superior waterproof and dustproof protection. Used for demanding power distribution needs, this connector guarantees a secure, stable connection through a threaded locking system-making it the ideal choice for harsh, high-performance environments where reliability is critical.

Export Markets, Supply Ability, and Payment Exchange

The DH20 Metal Waterproof Power Connector is a sought-after product with high supply ability for both domestic and international shipment. Major export markets include Europe, North America, Asia, and other global regions. Flexible payment can be arranged via popular exchange methods, ensuring convenient transactions. Reliable shipment procedures paired with competitive charges make this connector a preferred choice among importers, exporters, and distributors requiring consistent supply and streamlined processes.

FAQ's of DH20 500V 20A 3Pin Male Plug IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal:

Q: How does the DH20 3Pin Male Plug ensure reliable power connection in harsh environments?

A: The connector offers an IP67 rating, robust electroplated shell, UV resistance, and rubber sealing to protect against water, dust, and vibrations, making it suitable for demanding outdoor and industrial applications.

Q: What are the main benefits of its metal shell and silver-plated contacts?

A: The zinc alloy metal shell provides excellent corrosion resistance and durability, while silver-plated copper contacts ensure superior conductivity and reduced contact resistance for high-performance power transfer.

Q: Where can the DH20 connector be used?

A: It is ideal for industrial equipment, marine settings, automation systems, outdoor electrical distributions, and machinery, making it a versatile solution for a wide variety of challenging environments.

Q: What cable diameter does the DH20 3Pin Male Plug support?

A: The connector accommodates cables with an outer diameter ranging from 8mm to 12mm, ensuring compatibility with various power cabling standards.

Q: What is the process for connecting cables to this plug?

A: The DH20 connector uses a solder terminal connection method; you simply solder wires to the contact pins, then secure the cable using the rear cable clamp and locking ring for a tight, waterproof seal.

Q: When is it recommended to use this connector over standard plastic connectors?

A: It's best to use the DH20 Metal Waterproof Power Connector in environments requiring enhanced durability, waterproofing, anti-corrosion, and superior electrical performance compared to regular plastic connectors.
