DH24 400V 10A 12Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal

Name: DH24 400V 10A 12Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 765.0 INR
Availability: InStock

765.0 INR/Piece

Get a Price/Quote

Product Details:

Interface Solder terminal
Components 12-pin female socket, metal shell, solder terminals
Operating Temperature -40C to +85C
Power Source Electrical
Power Supply External
Input 12-pin female socket
Features Waterproof, dustproof, corrosion resistant, vibration resistant, secure locking
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

DH24 400V 10A 12Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 765.0 INR/Piece

Insulation Resistance >2000M (at 500V DC)
Standards Compliance CE, RoHS
Contact Material Copper alloy with silver plating
Contact Resistance 2.5m
Flame Retardancy UL94-V0
Salt Spray Resistance 48 hours
Cable Entry 10mm - 14mm
Pin Configuration 12 female pins, circular layout
Mounting Type Panel mount (front flange)
Shell Material Zinc alloy, nickel plated
Connector Type DH24 series circular connector
Sealing Method Compression gland with rubber sealing ring
Mating Cycle >500
Vibration Resistance 10Hz to 500Hz, 15g

DH24 400V 10A 12Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Product Specifications

Weight Approx. 220g
Thickness Shell thickness approx. 1.5mm
Color Silver (metal shell) and black
Function Power and signal connection
Interface Solder terminal
Size DH24 standard (approx. 36mm diameter)
Application Equipment, machinery, outdoor power distribution
Frequency 50/60Hz
Components 12-pin female socket, metal shell, solder terminals
Operating Temperature -40C to +85C
Input 12-pin female socket
Power Supply External
Capacity 10A per pin
Power Source Electrical
Supply Voltage 400V
Features Waterproof, dustproof, corrosion resistant, vibration resistant, secure locking
Product Type Waterproof power connector
Usage Industrial power and control systems
Current Rating 10A
Rated Voltage 400V AC/DC
Output 12-pin solder terminal
IP Rating IP67
Dimension (L*W*H) 67mm (length incl. flange) x 36mm (diameter) x 36mm

Insulation Resistance >2000M (at 500V DC)
Standards Compliance CE, RoHS
Contact Material Copper alloy with silver plating
Contact Resistance 2.5m
Flame Retardancy UL94-V0
Salt Spray Resistance 48 hours
Cable Entry 10mm - 14mm
Pin Configuration 12 female pins, circular layout
Mounting Type Panel mount (front flange)
Shell Material Zinc alloy, nickel plated
Connector Type DH24 series circular connector
Sealing Method Compression gland with rubber sealing ring
Mating Cycle >500
Vibration Resistance 10Hz to 500Hz, 15g

DH24 400V 10A 12Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Discover the popular DH24 400V 10A 12Pin Female Socket-an illustrious solution designed for monumental industrial demands. Featuring a redoubtable IP67 waterproof rating, this connector excels in robust, harsh environments. The metal shell, crafted from nickel-plated zinc alloy, safeguards against corrosion and vibration. Boasting a superior insulation resistance and flame-retardant construction, it assures durable power and signal connectivity. Pick yours today and grab a secure, high-performance solution for equipment, machinery, and outdoor power distribution. Reliability meets versatility and strength in the DH24-your next industrial essential awaits!

Competitive Edge & Versatile Applications

The DH24 400V 10A 12Pin Female Socket stands out for its monumental endurance, advanced sealing, and reliable electrical performance. Its competitive advantages include exceptional vibration resistance, high insulation resistance, and robust sealing for complete waterproof and dustproof protection. Specifically engineered for industrial power and control systems, it serves general connectivity and commercial applications such as equipment wiring, machinery installation, and outdoor power distribution, providing secure, enduring performance in demanding settings.

Export Market, Valuation & Transaction Terms

This redoubtable connector is a favored choice in both domestic and international markets, frequently shipped to Europe, the Middle East, and Southeast Asia. The valuation of each item is transparent and competitive, ensuring reliability for bulk and single shipments. Shipped goods are handled with careful packaging and prompt logistics. Payment terms are flexible, including T/T and L/C. For quality assurance, samples can be handed over upon request, helping buyers make informed decisions before large-scale orders.

FAQ's of DH24 400V 10A 12Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal:

Q: How does the DH24 10A 12Pin Female Socket ensure durability in industrial environments?

A: The connector features a zinc alloy, nickel-plated shell, robust insulation, IP67 waterproofing, and vibration resistance, making it exceptionally durable in demanding industrial and outdoor applications.

Q: What types of equipment can this connector be used with?

A: This product is designed for use with industrial machinery, outdoor power distribution panels, and control systems, supporting reliable power and signal connections.

Q: When are samples available for this connector?

A: Samples can generally be provided upon request, allowing buyers to evaluate the quality and compatibility before placing bulk orders.

Q: Where is the DH24 12Pin Female Socket most commonly distributed?

A: This connector is widely distributed in the Indian market as well as exported to regions like Europe, the Middle East, and Southeast Asia.

Q: What is the process for ordering and receiving shipped goods?

A: Customers can place orders with flexible payment terms; once the transaction is confirmed, goods are carefully packed and handed over to the shipping partner for prompt delivery.

Q: How can this connector benefit my commercial setup?

A: Its secure locking, compliance with CE and RoHS standards, and resistance to moisture and corrosion provide reliability and longevity, optimizing performance in commercial and industrial settings.
