YM20 400V 12A 7Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal

Name: YM20 400V 12A 7Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 505.0 INR
Availability: InStock

505.0 INR/Piece

Get a Price/Quote

Product Details:

Features Waterproof, Dustproof, Corrosion Resistant, Easy Installation
Thermal Conductivity Standard for plastic connectors
Power Source Electrical Cable
Components Plastic Shell, 7 Solder Terminals
Power Supply AC
Operating Temperature -40C to +80C
IP Rating IP67
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YM20 400V 12A 7Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 505.0 INR/Piece

Flame Resistance UL94 V-0
Locking Mechanism Threaded Coupling Nut
Number of Pins 7 Pin
Insulation Resistance >2000M at 500V DC
UV Resistance Yes
Material High-quality PC Flame-retardant Plastic Shell
Protection Cover Included
RoHS Compliance Yes
Connector Type Female Socket
Mounting Type Panel Mount
Cable Diameter Range 6mm to 12mm
Contact Resistance 5m
Contact Material Copper Alloy with Nickel Plating
Salt Spray Resistance >48 hours
Vibration Resistance 10~500Hz, 15g

YM20 400V 12A 7Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Product Specifications

Size YM20 (20mm Series)
Capacity 12A per Pin
Product Type Waterproof Power Connector
Weight Approx. 35g
Output Solder Terminal
Rated Voltage 400V AC
Dimension (L*W*H) Approx. 77mm x 27mm x 27mm
Color Black / Grey
Supply Voltage 400V AC
Usage Industrial Equipment / Power Connections
Input Solder Terminal
Components Plastic Shell, 7 Solder Terminals
Power Source Electrical Cable
Function Power Transmission
Features Waterproof, Dustproof, Corrosion Resistant, Easy Installation
Thermal Conductivity Standard for plastic connectors
Thickness Standard
IP Rating IP67
Interface 7 Pin Female Socket, Solder Terminal
Application Outdoor / Harsh Environment Power Distribution
Current Rating 12A per Pin
Frequency 50/60Hz
Operating Temperature -40C to +80C
Power Supply AC

Flame Resistance UL94 V-0
Locking Mechanism Threaded Coupling Nut
Number of Pins 7 Pin
Insulation Resistance >2000M at 500V DC
UV Resistance Yes
Material High-quality PC Flame-retardant Plastic Shell
Protection Cover Included
RoHS Compliance Yes
Connector Type Female Socket
Mounting Type Panel Mount
Cable Diameter Range 6mm to 12mm
Contact Resistance 5m
Contact Material Copper Alloy with Nickel Plating
Salt Spray Resistance >48 hours
Vibration Resistance 10~500Hz, 15g

YM20 400V 12A 7Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:400V
Withstanding voltage:2000V
Contact dimension:Phi 1.8*7
Insertion and extraction force:8.2N Max
Mating cycle:1700 Times
Temperature and humidity:-4080C; 40C, 85%RH
Screw torque:42-53 (N.m)

Designed for Harsh Environments

Built to meet the highest standards for outdoor and industrial use, the YM20 7-Pin Female Socket boasts an IP67 rating, UV resistance, and corrosion resistance, making it reliable even in harsh weather or high-vibration settings. The robust flame-retardant shell ensures extended life and safety.

Simple Installation and Secure Connection

The panel mount design, combined with a threaded coupling nut, allows effortless and safe installation onto equipment panels. Solder terminals offer solid, lasting connections, and the included protection cover keeps contacts safe during downtime or maintenance.

Optimal Power Transmission Versatility

With a 400V AC rating and 12A per pin capacity, the connector accommodates demanding industrial power needs. Its wide operating temperature range allows functionality from -40C to +80C, while compliance with RoHS standards provides assurance of high-quality, environmentally safe construction.

FAQ's of YM20 400V 12A 7Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal:

Q: How do I install the YM20 7-Pin Female Socket on my equipment panel?

A: To install, cut an appropriately sized mounting hole in your panel, insert the connector, and secure it using the threaded coupling nut. Connect your wires to the solder terminals and double-check for secure attachment before closing the protection cover.

Q: What harsh environments is this connector suitable for?

A: The YM20 socket's IP67 waterproof rating, UV resistance, flame retardancy (UL94 V-0), and excellent corrosion resistance make it ideal for outdoor setups, high-humidity areas, factories, and power distribution in demanding climates.

Q: When should I consider using a connector like the YM20 7-Pin Female Socket?

A: If your equipment requires reliable power connections in environments vulnerable to dust, moisture, vibration, and corrosion-such as industrial equipment, automation systems, or outdoor installations-the YM20 is an excellent choice.

Q: Where can this power connector be used?

A: It is widely used in industrial machinery, heavy-duty power distribution panels, outdoor lighting, marine equipment, and any site that demands durable, waterproof electrical connections.

Q: What are the benefits of the flame-retardant plastic shell and nickel-plated contacts?

A: The high-quality flame-retardant PC plastic shell enhances safety by resisting fire, while nickel-plated copper alloy contacts ensure excellent conductivity and corrosion protection, resulting in longer connector life and reliability.

Q: How does the locking mechanism ensure a secure connection?

A: The threaded coupling nut provides a firm, vibration-resistant attachment to the panel, reducing the risk of accidental disconnection and maintaining a stable connection even in environments with frequent movement.
