YM24 3A 19Pin Female Socket IP67 Waterproof Power Connector Flange Mount Plastic Shell Solder Terminal

Name: YM24 3A 19Pin Female Socket IP67 Waterproof Power Connector Flange Mount Plastic Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 643.0 INR
Availability: InStock

643.0 INR/Piece

Get a Price/Quote

Product Details:

Operating Temperature -40C to +80C
Output 19-pin socket output
Power Source External electrical source
Features IP67 waterproof, durable plastic shell, corrosion-resistant, secure flange mount
Input 19-pin socket connection
IP Rating IP67
Power Supply Electrical
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YM24 3A 19Pin Female Socket IP67 Waterproof Power Connector Flange Mount Plastic Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 643.0 INR/Piece

YM24 3A 19Pin Female Socket IP67 Waterproof Power Connector Flange Mount Plastic Shell Solder Terminal Product Specifications

Weight Approx. 65g
Interface 19-pin Solder Terminal
Power Supply Electrical
Color Black
Rated Voltage 250V AC/DC
Function 19-pin electrical power connectivity
Product Type Waterproof Power Connector
Operating Temperature -40C to +80C
Current Rating 3A
Application Indoor/Outdoor electrical applications, waterproof environments
Input 19-pin socket connection
IP Rating IP67
Frequency 50/60Hz
Capacity 3A per contact
Features IP67 waterproof, durable plastic shell, corrosion-resistant, secure flange mount
Supply Voltage Up to 250V
Size YM24 series standard
Components Plastic shell, 19-pin female solder terminal, flange mount
Power Source External electrical source
Output 19-pin socket output
Dimension (L*W*H) Approx. 42mm (flange diameter) x 60mm (length)
Usage Industrial equipment, outdoor power systems, machinery

Insulation Resistance >1000 M at 500V DC
Contact Material Copper alloy with gold/ni plating
Connector Gender Female
Shell Material High-strength engineering plastic
Contact Resistance 5 m
Standards Compliance RoHS compliant, CE certified
Mating Cycle >500 mating cycles
Mounting Type Flange mount with panel cut-out design
Sealing Rubber gasket for moisture resistance
Flammability Rating UL94-V0
Wire Connection Type Solder terminal

YM24 3A 19Pin Female Socket IP67 Waterproof Power Connector Flange Mount Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:latching lock
Contact diameter:phi 3.0x3
Operating voltage(AC.V.rms):500V
Withstand voltage(AC.V)1min:2500V
Temperature and humidity:-4080C, 40C, 85%RH

Rugged Waterproof Design

Engineered to withstand moisture, dust, and harsh environments, the YM24 3A 19Pin Female Socket delivers IP67-level protection with a resilient rubber gasket. This makes it perfectly suited for both indoor and outdoor uses, such as machinery, industrial equipment, and power systems requiring dependable, long-term waterproof connectivity.

Reliable Connectivity and Safety

With copper alloy contacts plated in gold/nickel and robust insulation resistance exceeding 1000M at 500V DC, this connector offers stable and secure signal and power transmission. Its UL94-V0 plastic shell and RoHS and CE certifications ensure compliance, safety, and resistance to flammability and corrosion.

FAQ's of YM24 3A 19Pin Female Socket IP67 Waterproof Power Connector Flange Mount Plastic Shell Solder Terminal:

Q: How do I install the YM24 3A 19Pin Female Socket with the flange mount design?

A: To install the connector, create a panel cut-out that matches the flange size (approx. 42mm diameter). Secure the flange mount to your panel using appropriate screws and connect your wires by soldering them to the 19-pin terminals, ensuring all seals are intact for waterproof performance.

Q: What environments is the IP67 waterproof rating suitable for?

A: The IP67 rating means the connector can withstand complete immersion in water up to 1 meter for 30 minutes, making it ideal for outdoor, industrial, or other moisture-prone environments where reliable electrical connections are required.

Q: When should I use a 19-pin socket like this for my electrical setup?

A: Use the YM24 19-pin socket when your application demands multiple circuit connectivity (up to 19 separate paths), higher voltage rating (up to 250V), and durable performance in harsh or outdoor conditions, such as in industrial machinery or exterior power systems.

Q: Where can this connector be used for optimal performance?

A: The YM24 3A 19Pin Female Socket is optimized for installation in industrial equipment, outdoor power cabinets, heavy machinery, and other environments where water or dust exposure is a concern.

Q: What process should be followed for wire connection to the socket?

A: Wires connect via solder terminals. Strip your wires, pre-tin if necessary, and solder each wire to its corresponding pin. Double check the wiring configuration for accuracy before securing the rear housing and mounting the flange for watertight closure.

Q: What are the primary benefits of using this connector?

A: Key benefits include excellent moisture and dust protection (IP67), long operational life (>500 mating cycles), reliable power contact up to 3A per pin, certified safety standards, and secure mounting for stability even in demanding applications.
