LP12 3A 8Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal

390.0 INR/Piece

Get a Price/Quote

Product Details:

Power Supply Wired
Components Metal shell, solder terminals, rubber sealing gasket
Features Waterproof, dustproof, corrosion-resistant metal shell, flange mount, compact size, secure connection
Operating Temperature -20C to 85C
Interface 8-pin solder terminals
Input Up to 8-pin signal or power input
IP Rating IP67
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP12 3A 8Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Price And Quantity

Price 390.0 INR/Piece
Minimum Order Quantity 100 Piece

Mounting Type Flange mount with 4 fixing holes
Connector Gender Female socket
Contact Resistance 5m
Wire Gauge Compatibility AWG 22-18
Contact Material Copper alloy with gold-plated contacts
Mating Cycle Durability >500 cycles
RoHS Compliance Yes
Flammability Rating UL94 V-0
Sealing Material Silicone rubber gasket
Shell Material Zinc alloy with nickel plating
Vibration Resistance Meets IEC 60512-4 standard
Insulation Resistance >2000M at 500V DC
Environmental Protection Moisture-resistant, UV proof

LP12 3A 8Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Product Specifications

Color Metallic/Silver
Features Waterproof, dustproof, corrosion-resistant metal shell, flange mount, compact size, secure connection
Product Type Waterproof Power Connector Socket
Usage Cable-to-device applications, industrial equipment
Weight Approx. 30g
Output Up to 8-pin signal or power output
Power Source Electrical wired connection
Dimension (L*W*H) 28 mm x 19 mm x 19 mm (approx)
Function Electrical Power/Signal Connection
Frequency 50/60 Hz
IP Rating IP67
Application Outdoor, equipment, machinery, automotive, communications
Current Rating 3A per pin
Rated Voltage 250V AC
Supply Voltage Up to 250V AC/DC
Operating Temperature -20C to 85C
Power Supply Wired
Thickness Body thickness approx. 2.5 mm
Capacity Up to 8 signal/power lines
Interface 8-pin solder terminals
Size Flange diameter 19mm, shell size 12mm
Components Metal shell, solder terminals, rubber sealing gasket
Input Up to 8-pin signal or power input

Mounting Type Flange mount with 4 fixing holes
Connector Gender Female socket
Contact Resistance 5m
Wire Gauge Compatibility AWG 22-18
Contact Material Copper alloy with gold-plated contacts
Mating Cycle Durability >500 cycles
RoHS Compliance Yes
Flammability Rating UL94 V-0
Sealing Material Silicone rubber gasket
Shell Material Zinc alloy with nickel plating
Vibration Resistance Meets IEC 60512-4 standard
Insulation Resistance >2000M at 500V DC
Environmental Protection Moisture-resistant, UV proof

LP12 3A 8Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:Easy locking type
Insertion and extraction force:0.6N Max
Wire specification:UL2464 24AWG*2C
Rated Current:3A
Contact dimension:Phi 1.0x6
Temperature and humidity:-4080C, 40C, 85%RH
Mating cycle: 1700 times

Superior Outdoor Performance

The LP12 8Pin Female Socket is engineered for challenging conditions, offering full IP67 waterproof and dustproof protection. Its robust metal shell and silicone rubber gasket guarantee longevity and safety in moisture-prone and UV-exposed environments. This makes it ideal for outdoor machinery, communication equipment, or automotive applications where reliability is crucial.

Easy and Secure Mounting

With a flange mount design and four fixing holes, installation is straightforward and stable. The solder terminals accommodate AWG 22-18 wires, allowing hassle-free and secure electrical connections. The compact form factor (28x19x19 mm) and flange diameter of 19mm make the connector well-suited for tight spots and modern equipment layouts.

Multi-Functional and Compliant

Handling up to 8 signal or power lines with 3A per pin, the LP12 supports diverse applications, from power transfer to signal connection. High insulation resistance and UL94 V-0 flammability rating ensure compliance and safety in demanding sectors. RoHS adherence further underscores its role in eco-friendly, industrial-grade electrical solutions.

FAQ's of LP12 3A 8Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal:

Q: How does the LP12 3A 8Pin Female Socket achieve waterproof and dustproof protection?

A: This connector features an IP67 rating, achieved through a precision-engineered zinc alloy shell and a silicone rubber sealing gasket. These elements combine to safeguard connections against water, dust, and moisture, making the connector suitable for challenging outdoor or industrial environments.

Q: What are the usage scenarios for this 8-pin flange mount connector?

A: The LP12 connector is designed for cable-to-device applications in fields such as industrial machinery, automotive systems, outdoor equipment, and communication devices. Its secure mounting and robust construction ensure reliable signal or power transfer where environmental protection is essential.

Q: When should I choose a connector with gold-plated copper alloy contacts?

A: Gold-plated copper alloy contacts provide low contact resistance (as low as 5m) and enhanced conductivity, making them ideal when consistent, high-quality signal or power transmission is needed-particularly in settings sensitive to corrosion or frequent cycles of connect/disconnect.

Q: Where should the LP12 connector be installed for best performance?

A: Optimal performance is achieved when the connector is used in environments exposed to moisture, dust, vibration, or UV, such as outdoor installations, industrial control panels, or automotive compartments. The flange mounting allows easy and stable integration into panels or casings.

Q: What is the process for wiring this connector?

A: Wiring involves soldering AWG 22-18 gauge wires to the 8-pin solder terminals. After securing the wires, the flange allows rigid mounting using four screws, and the included silicone gasket provides an environmental seal once mounted.

Q: How does the connector ensure durability and safe operation over time?

A: With nickel-plated zinc alloy housing and gold-plated contacts, the connector boasts superior corrosion resistance and a mating durability of over 500 cycles. It maintains insulation resistance over 2000M at 500V DC, supporting safe and reliable operation throughout its service life.

Q: What benefits does the LP12 8Pin Female Socket offer over standard connectors?

A: Benefits include high current handling (3A per pin), IP67 protection, advanced vibration resistance (IEC 60512-4), a compact and secure flange mount design, and robust compliance with RoHS and UL94 V-0 standards. These features result in a long-lasting, safe, and versatile connection solution for critical environments.
