LP16 10A 4Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal

Name: LP16 10A 4Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 404.0 INR
Availability: InStock

404.0 INR/Piece

Get a Price/Quote

Product Details:

Features Waterproof, Weatherproof, Anti-dust, Secure Locking, Sturdy Metal Body
Power Supply Electric
Input Solder Terminal
IP Rating IP67
Operating Temperature -20C to +85C
Components Metal shell, 4 pin female insert, solder terminals, flange mount plate
Output Solder Terminal
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP16 10A 4Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Price And Quantity

Price 404.0 INR/Piece
Minimum Order Quantity 100 Piece

LP16 10A 4Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Product Specifications

Operating Temperature -20C to +85C
Input Solder Terminal
IP Rating IP67
Color Silver (Metal Shell), Black Insulator
Application Industrial, Outdoor, Automation, LED Power, Equipment Power Supply
Power Source Electric
Usage Cable to device connection
Components Metal shell, 4 pin female insert, solder terminals, flange mount plate
Product Type 4 Pin Female Socket Connector
Features Waterproof, Weatherproof, Anti-dust, Secure Locking, Sturdy Metal Body
Function Power Connector
Frequency 50/60Hz
Size LP16 Series
Power Supply Electric
Dimension (L*W*H) Flange 26mm x 26mm, Overall Length 38mm (approx.)
Output Solder Terminal
Capacity 10A per contact
Interface Solder Cup Terminal
Rated Voltage 250V AC
Thickness Shell thickness approx. 1.6mm
Weight Approx. 25g
Supply Voltage 110-250V AC
Current Rating 10A

Clamp Range 4~8mm cable diameter
Mating Cycle Over 500 times
Contact Resistance <5m
Contact Material Copper alloy with silver plating
Shell Material Zinc Alloy; Plated
Withstand Voltage 1500V AC/min
Mounting Hole Diameter 20mm (Panel Cutout)
Insulation Resistance >2000M at 500V DC
Number of Pins 4
Connection Type Flange Mount
Locking System Bayonet

LP16 10A 4Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:400V
Temperature Rise:10A 30C ,12A 40C ,15A 50C
Contact Resistance:< 2.5m Ohm
Insertion and Extraction Force:1.2N Max
Mating Cycle:>1700 times
Working Temperature:-40i80C
Connection Mode:Quick plug connection

Exceptional Durability and Weatherproof Design

Crafted for use in harsh environments, the LP16 connector features an IP67 rating, safeguarding against water and dust ingress. The tough zinc alloy shell, coupled with a bayonet locking mechanism, provides secure, repeated connections suitable for industrial automation, outdoor equipment, and power distribution. Its silver-plated copper alloy contacts ensure low resistance and extended lifespan.

Easy Installation and Versatile Application

The flange mount design allows for straightforward panel installation with a 20mm cutout, and solder cup terminals offer secure, reliable wiring. Its clamp accommodates cables with a 4-8mm diameter, making it compatible with a wide range of applications - including LED power, industrial equipment, and automated systems. Supporting 10A at up to 250V AC, it meets demanding power needs.

FAQ's of LP16 10A 4Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal:

Q: How is the LP16 4Pin Female Socket installed in a device or panel?

A: This connector uses a flange mount design requiring a 20mm diameter panel cutout. After creating the hole, the socket is secured with screws through the flange, and wires are attached to the solder cup terminals for a stable, professional connection.

Q: What benefits does the IP67 rating provide for this power connector?

A: The IP67 waterproof and weatherproof rating ensures the socket is well protected from dust and temporary immersion in water, making it dependable for outdoor and industrial use where environmental exposure is common.

Q: When should I choose the LP16 4Pin Female Socket for my project?

A: Select this connector when you need a secure, high-current (up to 10A per contact), multi-pin solution for power delivery in demanding environments-such as automation equipment, LED lighting systems, or outdoor electrical enclosures.

Q: Where can the LP16 connector be used?

A: The LP16 4Pin socket is suitable for industrial automation, outdoor LED power supplies, equipment power connections, and any application requiring a rugged, waterproof flange mount connector. Its versatility spans manufacturing, automation, and environmental monitoring systems.

Q: What process is involved in wiring the LP16 connector?

A: Wiring involves soldering the electrical conductors directly onto the solder cup terminals. After soldering, ensure the cable's outer diameter (4-8mm) fits and fasten securely to maintain the IP67 rating and mechanical reliability.

Q: What advantages does the bayonet locking mechanism provide?

A: The bayonet locking system offers a secure, vibration-resistant connection that is quick and reliable to mate and unmate, even in frequent-use or mobile installations. It maintains electrical integrity and ease of use.
