LP16 10A 4Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal

424.0 INR/Piece

Get a Price/Quote

Product Details:

IP Rating IP67
Features Waterproof, Dustproof, Corrosion Resistant, Quick Coupling
Operating Temperature -20C to +85C
Power Source Wired
Output Wire Solder Terminal
Interface 4-Pin Male Plug
Usage Outdoor Power and Signal Connections
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP16 10A 4Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Price And Quantity

Price 424.0 INR/Piece
Minimum Order Quantity 100 Piece

LP16 10A 4Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Product Specifications

Weight Approx. 20g
Features Waterproof, Dustproof, Corrosion Resistant, Quick Coupling
Dimension (L*W*H) Approx. 60mm x 20mm x 20mm
Operating Temperature -20C to +85C
Power Source Wired
Current Rating 10A
IP Rating IP67
Capacity 10A Max Current
Size Shell size 16 mm
Output Wire Solder Terminal
Frequency 50/60Hz
Product Type 4 Pin Male Plug Connector
Thickness Refer to Dimension
Interface 4-Pin Male Plug
Supply Voltage 250V AC Max
Function Waterproof Power Connector for Electric Connections
Input Wire Solder Terminal
Application LED Lighting, Industrial Equipment, Solar Power
Power Supply Cable Power Feed
Components Plastic Shell, Metal Shell, Solder Terminal Contacts
Rated Voltage 250V AC
Usage Outdoor Power and Signal Connections
Color Black + Silver Grey

Mounting Type Panel Mount or Cable Mount
Wire Gauge Supported 18-16 AWG
Sealing Method Silicone Gasket
Flame Resistance UL94 V-0
Shell Material Nylon PA66 (Plastic) + Metal Alloy
Mechanical Life > 500 Mating Cycles
Contact Resistance 5 m
Suitable for Outdoor/Indoor Power and Signal Transmission
Contact Material Copper Alloy with Gold Plating
Cable Diameter Range 6mm - 8mm
Connection Method Soldering Terminals
Locking Mechanism Threaded Coupling Nut
Insulation Resistance > 500 M at 500V DC
Number of Pins 4

LP16 10A 4Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:Easy locking type
Insertion and extraction force:1.8N Max
Temperature and humidity:-4080C, 40C, 85%RH
Mating cycle:1700 times
Contact dimension:Phi 1.5*3
Operating Voltage:400V

Superior Durability and Reliability

Built with a combination of nylon PA66 and metal alloy, the LP16 10A 4Pin Male Plug is engineered to withstand harsh environments. It features gold-plated copper contacts, with sealing ensured by a silicone gasket, supporting over 500 mating cycles for dependable long-term use.

Versatile Applications

This connector is ideal for outdoor and indoor power and signal transmission in applications such as LED lighting, solar panels, and industrial machinery. Its IP67 rating safeguards against dust and water ingress, allowing worry-free use in demanding conditions.

Simple and Secure Installation

The LP16 plug integrates a threaded coupling nut for a secure connection and solder terminals for reliable electrical contact. It can be panel- or cable-mounted and supports wire gauges from 18-16 AWG, making installation straightforward for a wide range of users.

FAQ's of LP16 10A 4Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal:

Q: How is the LP16 10A 4Pin Male Plug installed?

A: You can install the LP16 connector using the soldering terminals to attach wires (18-16 AWG) and securing it with the threaded coupling nut, making it suitable for either panel or cable mounting.

Q: What environments can this connector be used in?

A: With an IP67 waterproof rating and a flame-resistant shell (UL94 V-0), the LP16 plug is suitable for both indoor and outdoor environments, even in locations exposed to dust, rain, or humidity.

Q: When should I use the LP16 4Pin Male Plug over other connectors?

A: Choose the LP16 plug when you need a reliable, waterproof, and dustproof connector for power or signal transmission-especially for applications in harsh or outdoor settings.

Q: Where is the LP16 10A 4Pin Male Plug typically applied?

A: It's commonly used in LED lighting systems, solar power installations, and industrial machinery-where secure and durable electric connections are critical.

Q: What is the benefit of the gold-plated copper alloy contacts?

A: Gold plating reduces oxidation and ensures low contact resistance, resulting in better conductivity, reliable connections, and extended product life.

Q: How does the threaded coupling nut improve the connection?

A: The threaded coupling nut provides a quick yet secure mechanical lock that prevents accidental disconnection and maintains the integrity of the waterproof seal.

Q: What is the process for preparing cables for this connector?

A: First, strip the insulation off your 18-16 AWG wires, then solder them to the terminal contacts. The connector accommodates cable diameters from 6mm to 8mm for a tight and secure fit using the silicone gasket.
