LP16 400V 10A 3Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal

363.0 INR/Piece

Get a Price/Quote

Product Details:

Usage Outdoor/industrial power connections
Power Source Electric
IP Rating IP67
Components 3 Pin female socket, metal shell, fixing accessories
Interface Solder terminal
Output Power output through solder terminal
Features Waterproof, dustproof, corrosion resistant, quick connect/disconnect
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP16 400V 10A 3Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 363.0 INR/Piece

Locking System Threaded coupling with rubber gasket
Material Metal shell with flame retardant plastic insert
Cable Outer Diameter Accepted 5-8mm
Mounting Type Panel Mount
Sealing Method Rubber O-ring inside housing
Contact Material Copper alloy, gold plated contacts
Gender Female
Number of Pins 3 Pin

LP16 400V 10A 3Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Product Specifications

Components 3 Pin female socket, metal shell, fixing accessories
Capacity 10A continuous
Interface Solder terminal
Rated Voltage 400V AC
Supply Voltage 400V
Function Female socket for power connection
Output Power output through solder terminal
Features Waterproof, dustproof, corrosion resistant, quick connect/disconnect
Application Panels, Machinery, Power Distribution
Usage Outdoor/industrial power connections
Power Source Electric
IP Rating IP67
Dimension (L*W*H) Approx. 58mm 23mm 23mm
Frequency 50/60Hz
Thickness Standard (Metal Shell)
Size 16mm (Panel cutout diameter)
Color Metallic Silver/Black
Current Rating 10A
Input 3 Pin receptacle
Power Supply Electrical
Product Type Waterproof Power Connector
Operating Temperature -25C to +80C
Weight Approx. 30g

Locking System Threaded coupling with rubber gasket
Material Metal shell with flame retardant plastic insert
Cable Outer Diameter Accepted 5-8mm
Mounting Type Panel Mount
Sealing Method Rubber O-ring inside housing
Contact Material Copper alloy, gold plated contacts
Gender Female
Number of Pins 3 Pin

LP16 400V 10A 3Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:Easy locking type
Insertion and extraction force:1.8N Max
Temperature and humidity:-4080C, 40C, 85%RH
Mating cycle:1700 times
Contact dimension:Phi 1.5*3
Operating Voltage:400V
Diameter range:79mm
Withstand voltage (AC) 1min:2500V

Reliable Power Connection for Demanding Environments

Engineered with a rugged metal shell and an advanced sealing system, the LP16 connector delivers stable power connectivity in both indoor and outdoor settings. Its gold-plated contacts and solder terminals provide long-term electrical performance, making it ideal for industrial panels, machinery and power distribution networks. The IP67 rating ensures the socket remains operational in harsh or wet environments.

Easy Installation with Secure Threaded Coupling

The connector's panel mount design and threaded coupling system simplify installation, while the rubber O-ring guarantees a watertight seal. Its user-friendly structure allows for swift, reliable interface with minimal maintenance. Whether you're assembling new electrical panels or upgrading existing systems, this socket ensures seamless power integration with enhanced protection.

FAQ's of LP16 400V 10A 3Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal:

Q: How is the LP16 3Pin Female Socket installed for panel mount applications?

A: To install, prepare a panel cutout of 16mm diameter, insert the socket, and secure it using the provided fixing accessories. The threaded coupling and rubber gasket ensure the connection is firmly sealed against water and dust ingress.

Q: What makes the LP16 connector suitable for outdoor or industrial use?

A: This connector features a metal shell, flame retardant plastic insert, and gold-plated copper alloy contacts. Its IP67 rating, provided by a rubber O-ring inside the housing, protects against moisture, dust, and corrosion, making it ideal for demanding environments.

Q: When should I use a 3 pin 400V 10A female socket in my electrical system?

A: The socket is perfect for scenarios requiring secure, high-capacity power connections, such as machinery, power distribution panels, or other industrial systems that operate at up to 400V and 10A.

Q: Where is the LP16 socket commonly used?

A: It is widely utilized in industrial control panels, power supply units, machinery, and outdoor electrical installations, particularly where waterproof and durable power connections are necessary.

Q: What is the process for connecting wires to the LP16 socket?

A: Wires are attached via solder terminals inside the socket. Simply strip the cable ends, insert them through the back opening, and solder to the designated terminals following the pin configuration.

Q: What are the benefits of using gold-plated copper alloy contacts in this connector?

A: Gold-plated contacts offer enhanced electrical conductivity, resistance to oxidation, and low contact resistance, ensuring reliable power transfer over extended periods and reducing maintenance frequency.

Q: How does the sealing method protect against environmental hazards?

A: The integrated rubber O-ring and gasket form a tight barrier inside the metal housing, providing IP67-level protection to keep moisture, dust, and contaminants from affecting the electrical connection.
