LP20 10A 7Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal

593.0 INR/Piece

Get a Price/Quote

Product Details:

Usage Panel mount connection for waterproof applications
Power Supply Electric
IP Rating IP67
Operating Temperature -40C to +85C
Components 1 x Panel mount socket, fixing nut, sealing gasket
Interface Solder terminal
Features Waterproof, dustproof, robust metal shell, vibration resistant
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 10A 7Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Price And Quantity

Price 593.0 INR/Piece
Minimum Order Quantity 100 Piece

Electrical Life Over 500 insertions/withdrawals
Contact Resistance <2.5m
Insulation Resistance >2000M at 500V DC
Contact Material Copper alloy with gold plating
Cable Range Suitable for 6-12mm diameter cable
Flame Retardant Grade UL94-V0
Mounting Hole Diameter 20mm
Seal Material Silicone rubber
Number of Pins 7
Shell Material Zinc alloy with nickel plating
Connection Method Soldering
Mating Cycle Durability >500 cycles
Environmental Protection Corrosion-resistant, UV resistant
Locking Type Threaded coupling

LP20 10A 7Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Product Specifications

Power Supply Electric
Interface Solder terminal
Supply Voltage Up to 500V AC
Usage Panel mount connection for waterproof applications
Frequency 50/60 Hz
Input 7-pin female solder terminal
Size 20mm shell size
Features Waterproof, dustproof, robust metal shell, vibration resistant
Dimension (L*W*H) Approx. 35mm x 20mm x 20mm
Current Rating 10A
IP Rating IP67
Output Power and signals via mated connector
Weight Approx. 38g
Application Industrial equipment, outdoor power devices, automation systems
Rated Voltage 500V AC
Operating Temperature -40C to +85C
Color Metallic silver
Function Power connection and signal transmission
Product Type Female socket connector
Capacity 10A maximum current
Power Source Electrical connection
Components 1 x Panel mount socket, fixing nut, sealing gasket

Electrical Life Over 500 insertions/withdrawals
Contact Resistance <2.5m
Insulation Resistance >2000M at 500V DC
Contact Material Copper alloy with gold plating
Cable Range Suitable for 6-12mm diameter cable
Flame Retardant Grade UL94-V0
Mounting Hole Diameter 20mm
Seal Material Silicone rubber
Number of Pins 7
Shell Material Zinc alloy with nickel plating
Connection Method Soldering
Mating Cycle Durability >500 cycles
Environmental Protection Corrosion-resistant, UV resistant
Locking Type Threaded coupling

LP20 10A 7Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:400V
Withstanding voltage:2500V
Mating cycle:1700 Times
Temperature and humidity:-40+80C; 40C, 85%RH
Contact dimension:Phi 2.7x3
Screw torque:42-53 (N.m)

Engineered for Durability and Reliability

Crafted with a zinc alloy shell, gold-plated copper contacts, and a silicone rubber seal, the LP20 7Pin Female Socket ensures resistance to corrosion, vibrations, and UV exposure. It is designed to withstand frequent usage, enduring more than 500 mating cycles, and maintains its performance in extreme temperatures ranging from -40C to +85C.

Superior Waterproof and Dustproof Protection

With an IP67 rating, this connector is completely protected against dust ingress and temporary immersion in water. The rugged metal shell and high-quality sealing materials make it ideal for harsh outdoor environments and industrial applications where reliability is paramount.

Flexible Panel Mounting Solution

Designed for easy installation, the 20mm mounting hole diameter and threaded coupling ensure secure attachment. Solder terminals support robust connections, accommodating cable diameters from 6mm to 12mm. This makes the LP20 socket a preferred choice for power and signal management in a broad range of automation systems and outdoor devices.

FAQ's of LP20 10A 7Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal:

Q: How does the LP20 7Pin Female Socket ensure a waterproof connection?

A: The LP20 socket is designed with an IP67 rating, employing a silicone rubber seal and precision metal shell to prevent dust and water ingress, ensuring reliable operation even in wet or outdoor environments.

Q: What are the benefits of the gold-plated copper contacts?

A: Gold-plated copper contacts provide low contact resistance (less than 2.5m) and excellent conductivity, minimizing power loss. The plating also resists oxidation and corrosion, significantly increasing the connector's lifespan and reliability.

Q: Where can the LP20 7Pin Female Socket be used?

A: This connector is ideal for industrial equipment, outdoor power devices, and automation systems in need of secure, waterproof, and durable panel mount power connections.

Q: What is the process for mounting and connecting the LP20 socket?

A: To install, secure the socket into a 20mm panel hole using the included fixing nut and gasket. Cables (6-12mm diameter) are soldered to the terminals, ensuring a firm and vibration-resistant interface before mate-locking with a threaded coupling.

Q: When should I use a solder terminal connection?

A: Solder terminals are preferred when a firm, low-resistance, and vibration-resistant connection is required. This method is especially suitable for permanent installations in industrial or outdoor applications.

Q: What makes the LP20 connector resistant to harsh environments?

A: The zinc alloy housing with nickel plating, silicone rubber seal, and gold-plated contacts provide excellent resistance to corrosion, UV radiation, vibrations, and high temperatures, ensuring consistent performance in challenging conditions.

Q: How does the LP20 socket support electrical safety?

A: With insulation resistance over 2000M at 500V DC and flame retardant grade UL94-V0, the LP20 socket delivers robust electrical insulation and resists fire hazards, supporting safety in demanding electrical installations.
