LP20 20A 3Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal

Name: LP20 20A 3Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 470.0 INR
Availability: InStock

470.0 INR/Piece

Get a Price/Quote

Product Details:

Features Waterproof, Dustproof, Durable, Anti-corrosion
Input Solder terminal, 3 Pin Male
IP Rating IP67
Usage Power connection in harsh environments
Operating Temperature -40C to +80C
Output Solder connection to cable
Interface 3 Pin Solder Terminal
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 20A 3Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Price And Quantity

Price 470.0 INR/Piece
Minimum Order Quantity 100 Piece

LP20 20A 3Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Product Specifications

Operating Temperature -40C to +80C
Usage Power connection in harsh environments
Output Solder connection to cable
Interface 3 Pin Solder Terminal
Rated Voltage 500V AC, 50/60Hz
Size LP20 series standard
Application Outdoor power distribution, industrial equipment, LED lighting
Power Source Electric
Frequency 50/60Hz
Components Plastic + Metal shell, 3 solder terminals
Power Supply Electric
Product Type Waterproof Power Connector Plug
Color Black + Blue
Capacity 20A
Dimension (L*W*H) 70mm(L) x 32mm(Diam.)
Function Reliable waterproof power connection
Supply Voltage 500V max
Input Solder terminal, 3 Pin Male
Features Waterproof, Dustproof, Durable, Anti-corrosion
Current Rating 20A
IP Rating IP67
Weight Approx. 70g

Contact Resistance <5m
Mounting Type Cable mount
Connector Type Male plug
Cable Diameter Range 6-12mm
Insulation Resistance >2000M (500V DC)
Mechanical Life >500 mating cycles
Standards Compliance RoHS, CE
Flame Retardancy UL94-V0
Contact Material Copper alloy (gold plated)
Sealing Gasket Silicone rubber
Locking Mechanism Threaded coupling
Shell Material High strength plastic + metal

LP20 20A 3Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Rated Current:20A
Contact resistance:< 1.0mOhm
Withstanding voltage:2500V
Mating cycle:> 1700 Times
Contact dimension:Phi 2.7x3
Temperature and humidity:-40+80C; 40C, 85%RH
Screw torque:42-53(N.m)

Reliable Waterproof Power Connector

Engineered to perform flawlessly in harsh environments, the LP20 plug features an IP67 waterproof rating, making it ideal for outdoor and industrial use. Its robust sealing mechanisms and flame-retardant shell keep moisture, dust, and contaminants at bay, ensuring a stable power connection wherever you need.

Durable Build and Safety Assurance

Constructed from high-strength plastic and metal, the LP20 connector is designed for longevity. It supports up to 20A at 500V AC, uses gold-plated copper contacts for optimal conductivity, and meets RoHS and CE standards for safety and environmental compliance.

Simple Installation and Versatile Application

With a threaded coupling for secure locking, solder terminals for easy wire connection, and compatibility with cable diameters from 6 to 12mm, the LP20 adapts effortlessly to diverse power distribution needs in industrial, outdoor, and lighting installation scenarios.

FAQ's of LP20 20A 3Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal:

Q: How do I install the LP20 3Pin Male Plug onto my power cable?

A: To install the LP20 connector, strip the cable insulation as per your wire size, solder your wires to the designated pins, and thread the cable gland for a secure fit. Finally, use the plug's threaded coupling mechanism to lock the shell and ensure its IP67-rated seal.

Q: What environments is this connector best suited for?

A: The LP20 plug is designed for harsh conditions such as outdoor power distribution, industrial manufacturing, and waterproof LED lighting. Its IP67 rating and flame-retardant casing make it highly resistant to water, dust, and environmental hazards.

Q: When should I choose a plug with an IP67 rating?

A: You should use an IP67-rated plug like the LP20 when your applications demand reliable protection against water immersion and dust ingress, such as in outdoor installations, factories, or environments exposed to variable weather.

Q: What are the benefits of a threaded coupling and silicone seal in this connector?

A: The threaded coupling ensures a stable mechanical connection that resists loosening from vibration, while the silicone rubber gasket achieves a waterproof and dustproof seal, protecting electrical contacts and prolonging service life.

Q: Can this connector handle high-current applications?

A: Yes, the LP20 is rated for a maximum current of 20A and a supply voltage up to 500V AC, making it suitable for demanding power distribution applications in industrial equipment and large-scale LED lighting systems.

Q: Where can this connector be used in India?

A: It is suitable for distribution, export, import, manufacturing, trading, and wholesale applications across India, wherever robust, weather-resistant electrical connections are required-both outdoors and in industrial settings.
