LP20 5A 14Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal

545.0 INR/Piece

Get a Price/Quote

Product Details:

Features Waterproof, Dustproof, Secure Locking, Durable Construction
Output 14 Pin Cable Output
IP Rating IP67
Input 14 Pin Male Plug
Usage Electric Cable Connection
Components Plug Shell, Metal Insert, Sealing Gasket
Operating Temperature -25C to +85C
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 5A 14Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Price And Quantity

Price 545.0 INR/Piece
Minimum Order Quantity 100 Piece

Sealing Method Rubber O-Ring
Mating Cycle >500 Cycles
Gender Male Plug
Locking Mechanism Threaded Coupling
Cable Diameter Range 6mm-12mm
Material Plastic & Metal Shell
Contact Termination Solder
Mounting Type Inline Cable Mount
Contact Resistance <1.0 m
Contact Material Copper Alloy with Gold Plating
Number of Contacts 14 Pins (Male)
Insulation Resistance >2000 M at 500V DC
Flammability Rating UL94-V0

LP20 5A 14Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Product Specifications

Usage Electric Cable Connection
Operating Temperature -25C to +85C
Components Plug Shell, Metal Insert, Sealing Gasket
Color Black and Silver
Frequency 50/60Hz compatible
Rated Voltage 500V AC
Current Rating 5A per Pin
Size Shell Size 20mm (LP20 Series)
Weight Approx. 52g
Power Supply Solder Terminal Connection
Function Waterproof Power Connection
Application Industrial, Automation, LED Lighting, Outdoor Equipment
Power Source External Power Cable
Interface Solder Terminal
Dimension (L*W*H) Approx. 80mm x 32mm x 32mm
Thickness Standard Shell Thickness
Supply Voltage Up to 500V AC/DC
Product Type IP67 Power Connector
Features Waterproof, Dustproof, Secure Locking, Durable Construction
Output 14 Pin Cable Output
Capacity 14 Pin Connections, Each Pin Max. 5A
IP Rating IP67
Input 14 Pin Male Plug

Sealing Method Rubber O-Ring
Mating Cycle >500 Cycles
Gender Male Plug
Locking Mechanism Threaded Coupling
Cable Diameter Range 6mm-12mm
Material Plastic & Metal Shell
Contact Termination Solder
Mounting Type Inline Cable Mount
Contact Resistance <1.0 m
Contact Material Copper Alloy with Gold Plating
Number of Contacts 14 Pins (Male)
Insulation Resistance >2000 M at 500V DC
Flammability Rating UL94-V0

LP20 5A 14Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:250V
Withstanding voltage:2500V
Mating cycle:> 1700 Times
Contact dimension:Phi 2.7x3
Temperature and humidity:-40+80C; 40C, 85%RH
Screw torque:42-53 (N.m)

Rugged Waterproof Performance

Constructed with an IP67-rated shell and precision-engineered rubber O-ring, the LP20 connector offers optimal protection from water and dust. The UL94-V0 flammability rating ensures safety in various industrial and outdoor scenarios, and the robust build promises durability even under demanding conditions.

Versatile Applications

Thanks to its high current and voltage ratings, as well as reliable solder termination, the LP20 14Pin Male Plug is suitable for automation, LED installations, industrial equipment, and outdoor environments. Its compatibility with multiple cable sizes allows for flexible integration across diverse projects.

Secure and Reliable Connection

The threaded coupling mechanism ensures a tight, vibration-resistant connection. Gold-plated copper alloy contacts minimize resistance and signal loss, while the durable plastic and metal housing extends longevity over more than 500 mating cycles, making the LP20 connector a dependable choice.

FAQ's of LP20 5A 14Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal:

Q: How do I install the LP20 5A 14Pin Male Plug connector?

A: To install, strip your cable to the appropriate length, solder each conductor to the respective terminal on the connector, then assemble the connector shell, ensuring the rubber O-ring is correctly seated. Tighten the threaded coupling for a secure, waterproof fit.

Q: What types of applications are suitable for this connector?

A: The LP20 14Pin Male Plug is ideal for industrial automation, LED lighting installations, outdoor machinery, and applications requiring a durable, waterproof connector for high-current or multi-signal cables.

Q: Where can I use the LP20 connector considering its IP67 rating?

A: You can use the connector in environments exposed to water, dust, and outdoor weather. It is suitable for use in both indoor and outdoor settings, industrial sites, and any place where water ingress protection is essential.

Q: What benefits does the gold-plated copper alloy contact offer?

A: Gold-plated copper alloy contacts provide superior electrical conductivity and excellent corrosion resistance, ensuring low contact resistance and long-term reliability even in harsh or humid environments.

Q: What is the cable diameter range compatible with this connector?

A: The LP20 14Pin Male Plug supports cables with diameters from 6mm to 12mm, covering a broad range of industrial and commercial cable types for flexible installation options.

Q: How durable is the connector during repeated use?

A: Rated for over 500 mating cycles, the LP20 connector maintains performance through repeated connections and disconnections, making it suitable for applications where regular maintenance or setup changes are required.

Q: What process ensures the connector's waterproof and dustproof performance?

A: The connector's sealing performance is achieved through a combination of an IP67-rated plastic and metal shell, a precisely engineered rubber O-ring, and a threaded coupling mechanism that tightly secures and seals the connection.
