LP20 5A 9Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal

436.0 INR/Piece

Get a Price/Quote

Product Details:

Operating Temperature -40C to +85C
Components Socket, Panel Mounting Hardware
Power Supply Panel Mount Supply Connection
Power Source Wired panel connection
Output 9 Pin Female Socket
Features Waterproof, Dustproof, Durable Metal Shell, Corrosion Resistance, Quick Connect/Disconnect
Interface Solder Terminal
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 5A 9Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Price And Quantity

Price 436.0 INR/Piece
Minimum Order Quantity 100 Piece

Wire Size Compatibility Up to 1.5mm2 (AWG 16)
Shell Material Zinc Alloy with Nickle Plating
Flame Resistance UL94-V0
Mounting Type Panel Mount with Flange
Contact Material Copper Alloy with Gold Plating
Mating Cycle Durability Over 500 cycles
Connector Gender Female
Standards Compliance RoHS Compliant
Locking Method Threaded Coupling
Sealing Method Double O-ring

LP20 5A 9Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Product Specifications

IP Rating IP67
Size LP20 series standard
Output 9 Pin Female Socket
Supply Voltage Up to 500V AC/DC
Rated Voltage 500V AC (1 minute)
Product Type Power Connector Socket
Power Supply Panel Mount Supply Connection
Power Source Wired panel connection
Application Outdoor and Harsh Environment Connections
Capacity 9 pins; 5A per pin
Input Panel Solder Terminals
Function Power/Signal Transmission
Features Waterproof, Dustproof, Durable Metal Shell, Corrosion Resistance, Quick Connect/Disconnect
Interface Solder Terminal
Weight Approx. 26g
Usage Industrial Equipment, Machinery, Power Distribution
Dimension (L*W*H) Panel cut-out: 20mm diameter (body diameter approx. 24.7mm x length approx. 45.2mm)
Operating Temperature -40C to +85C
Color Silver (Metallic)
Current Rating 5A per pin
Components Socket, Panel Mounting Hardware

Wire Size Compatibility Up to 1.5mm2 (AWG 16)
Shell Material Zinc Alloy with Nickle Plating
Flame Resistance UL94-V0
Mounting Type Panel Mount with Flange
Contact Material Copper Alloy with Gold Plating
Mating Cycle Durability Over 500 cycles
Connector Gender Female
Standards Compliance RoHS Compliant
Locking Method Threaded Coupling
Sealing Method Double O-ring

LP20 5A 9Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:400V
Withstanding voltage:2500V
Mating cycle:1700 Times
Temperature and humidity:-40+80C; 40C, 85%RH
Contact dimension:Phi 2.7x3
Screw torque:42-53 (N.m)

Engineered for Extreme Environments

Constructed with a zinc alloy shell and dual O-ring sealing, the LP20 5A 9Pin Female Socket resists water, dust, and corrosion, achieving an IP67 rating. This makes it perfectly suited for outdoor applications or harsh industrial settings, guaranteeing reliable operation in tough conditions.

Precision Power and Signal Connectivity

Equipped with nine gold-plated copper alloy pins, this connector provides stable and high-quality power or signal transmission with a 5A per pin capacity. UL94-V0 flame resistance and RoHS compliance ensure safety and environmental responsibility across industrial and commercial deployments.

Effortless Panel Mounting & Secure Locking

Featuring a panel mount design with flange and durable threaded coupling, the connector installs easily onto panels with a standard 20mm cut-out. The solder terminals support up to 1.5mm2 wires, while the quick disconnect mechanism streamlines maintenance and replacement processes.

FAQ's of LP20 5A 9Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal:

Q: How should the LP20 5A 9Pin Female Socket be installed on a panel?

A: The socket is designed for panel mount installation with a flange. To install, create a 20mm diameter cut-out, position the connector, and secure it using the provided mounting hardware. Wires up to 1.5mm2 can be easily soldered to the terminal contacts.

Q: What environments is the LP20 connector suitable for?

A: Thanks to its IP67 waterproof and dustproof rating, as well as corrosion-resistant metal shell, the LP20 socket is ideal for outdoor use and harsh industrial environments such as power distribution, machinery, and various types of equipment exposed to moisture or debris.

Q: When should I choose the LP20 5A 9Pin Female Socket over other connectors?

A: Select the LP20 connector when you require a reliable solution for power and signal transmission in environments where exposure to water, dust, or harsh weather is expected. Its robust build and high mating cycle durability make it suitable for applications demanding longevity and performance.

Q: Where can this panel mount socket be used in real-world applications?

A: This connector is used in industrial equipment, machinery, power distribution panels, and other outdoor electronic systems that require secure, reliable, and waterproof electrical connections.

Q: What is the process for soldering wires to the connector terminals?

A: Strip the wire ends to the appropriate length (compatible up to 1.5mm2), insert them into the solder terminals, and apply solder to ensure a solid electrical and mechanical connection. Allow the solder to cool before assembling the connector onto the panel.

Q: What are the key benefits of using this specific connector?

A: The LP20 5A 9Pin Female Socket offers superior protection against water, dust, and corrosion, ensuring long service life. Its high current capacity, quick connect/disconnect design, and secure locking make installation and maintenance straightforward and reliable for industrial users.
