YF24 500V 20A 3Pin PowerCON IP67 Waterproof Male Plug Panel Connector Plastic Shell Solder Terminal

Name: YF24 500V 20A 3Pin PowerCON IP67 Waterproof Male Plug Panel Connector Plastic Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 447.0 INR
Availability: InStock

447.0 INR/Piece

Get a Price/Quote

Product Details:

Usage Panel mount power input
Power Supply AC
Output To cable or device
Input 3-pin male PowerCON
Operating Temperature -25C to +80C
IP Rating IP67
Power Source Wired
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YF24 500V 20A 3Pin PowerCON IP67 Waterproof Male Plug Panel Connector Plastic Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 447.0 INR/Piece

Ambient Humidity 95% RH
Contact Material Copper alloy with silver plating
Mating Cycle Durability >500 cycles
Mounting Type Flange panel mount
Terminal Type Solder cup
Protection Class Class I
Withstand Voltage 2000V AC/min
Flammability Rating UL94 V-0
Locking Mechanism Twist lock for secure connection
Shell Material High-grade polyamide (nylon) PA66
Insulation Resistance >1000M at 500VDC

YF24 500V 20A 3Pin PowerCON IP67 Waterproof Male Plug Panel Connector Plastic Shell Solder Terminal Product Specifications

Operating Temperature -25C to +80C
Size YF24
IP Rating IP67
Weight Approx. 42g
Rated Voltage 500V
Current Rating 20A
Power Source Wired
Function Power connection for electrical devices
Application Power distribution boxes, audio equipment, industrial control
Capacity 20A
Color Black
Dimension (L*W*H) Approx. 72mm x 34mm x 34mm
Usage Panel mount power input
Product Type Connector
Power Supply AC
Output To cable or device
Interface Panel mount, 3-pin solder terminal
Frequency 50/60Hz
Thickness 3.5mm (panel flange)
Input 3-pin male PowerCON
Components Plastic shell, metal pins, solder terminals
Supply Voltage 500V AC max
Features Waterproof, dustproof, durable plastic shell

Ambient Humidity 95% RH
Contact Material Copper alloy with silver plating
Mating Cycle Durability >500 cycles
Mounting Type Flange panel mount
Terminal Type Solder cup
Protection Class Class I
Withstand Voltage 2000V AC/min
Flammability Rating UL94 V-0
Locking Mechanism Twist lock for secure connection
Shell Material High-grade polyamide (nylon) PA66
Insulation Resistance >1000M at 500VDC

YF24 500V 20A 3Pin PowerCON IP67 Waterproof Male Plug Panel Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting Mode:Fast Locking
Cable Specification:2.5mm2 4mm2 /1412AWG
Diameter Range:8mm 12mm
Operating Voltage:500V
Durability:> 500 mating & unmating cycles
Temperature Rating:-40C80C

Advanced Safety and Reliability

Built with a high-grade polyamide (PA66) shell and copper alloy contacts coated with silver, the YF24 connector ensures dependable power transmission. Its twist-lock system prevents accidental disconnection, while the IP67 rating certifies resistance to water and dust. With a high insulation resistance of over 1000M at 500VDC and a flammability UL94 V-0 rating, this connector offers elevated safety in electrical installations.

Versatile Industrial Applications

The panel mount YF24 3Pin PowerCON connector is engineered for rigorous use in power distribution boxes, audio visual equipment, and industrial control systems. Designed for flexibility, its flange-mount style allows installation on a variety of panels and enclosures, making it suitable for use in commercial, stage, or factory settings. Its durability of over 500 mating cycles ensures lasting performance.

Effortless Installation and Use

With a solder cup terminal, the YF24 connector supports secure cable attachment, enhancing electrical contact quality. Its compact design (approx. 72mm x 34mm x 34mm) and lightweight profile (approx. 42g) facilitate straightforward panel integration. The twist-lock mechanism allows for quick, secure, and tool-free mating, making it user-friendly for professionals and installers alike.

FAQ's of YF24 500V 20A 3Pin PowerCON IP67 Waterproof Male Plug Panel Connector Plastic Shell Solder Terminal:

Q: How is the YF24 PowerCON connector installed into a panel?

A: The YF24 connector is designed for flange panel mounting. Simply insert the 3-pin male connector into a pre-cut panel hole, align the flange, and secure it using screws. Solder the wires to the corresponding terminals via the solder cups to complete the power connection.

Q: What benefits does the IP67 rating offer for this connector?

A: The IP67 rating ensures that the YF24 connector is fully protected against dust ingress and can withstand immersion in water up to 1 meter for 30 minutes, making it ideal for outdoor or harsh industrial environments.

Q: When should I use this connector in my electrical setup?

A: This connector is suitable for applications requiring a robust, waterproof, and secure power input-such as power distribution boxes, audio equipment, or industrial machinery operating up to 500V and 20A.

Q: Where can the YF24 PowerCON connector be applied?

A: It is commonly used in industrial control panels, stage lighting rigs, power distribution units, and outdoor audio equipment, where reliable and weather-resistant power connections are essential.

Q: What is the process for wiring cables to the YF24 connector?

A: To wire cables, strip the wire ends, insert them into the solder cup terminals, and solder them securely. This ensures optimal electrical contact and long-term durability.

Q: What makes the YF24 connector advantageous compared to other panel mount connectors?

A: It offers high current capacity, durable waterproof and dustproof cover (IP67), a secure twist lock, and a high-grade flame-resistant shell for superior safety and reliability over 500 mating cycles.

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number
