YM20 250V 5A 12Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal

Name: YM20 250V 5A 12Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 397.0 INR
Availability: InStock

397.0 INR/Piece

Get a Price/Quote

Product Details:

Usage Outdoor and industrial
Interface Solder terminal, 12 pin male plug
Features Waterproof, dustproof, corrosion resistant, plastic shell, easy installation, secure locking
Operating Temperature -20C to +85C
Components Plastic shell, solder terminal, sealing gasket
Input Male end, 12 pin
Power Source Electric
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YM20 250V 5A 12Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 397.0 INR/Piece

YM20 250V 5A 12Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Product Specifications

Application LED lighting, automation, machinery, marine, outdoor power
Product Type Waterproof power connector
Usage Outdoor and industrial
Capacity 5A per pin
Interface Solder terminal, 12 pin male plug
Features Waterproof, dustproof, corrosion resistant, plastic shell, easy installation, secure locking
IP Rating IP67
Operating Temperature -20C to +85C
Supply Voltage 250V
Weight Approx. 46g
Components Plastic shell, solder terminal, sealing gasket
Color Black
Power Supply Electrical
Function Waterproof power connection
Input Male end, 12 pin
Power Source Electric
Current Rating 5A
Dimension (L*W*H) Approx. 75mm (L), 27mm (Dia)
Output 12 circuit connection
Size YM20 standard
Rated Voltage 250V AC

Contact Resistance 5m
Mounting Type Cable mount
Sealing Method Rubber gasket ring
Insulation Resistance 2000M (500VDC)
Wire Specification Suitable for 24-16AWG cable
Shell Material High strength plastic (nylon PA66)
Contact Material Copper alloy, silver plated

YM20 250V 5A 12Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Withstanding voltage:1500V
Contact dimension:Phi 1*12
Operating Voltage:250V
Insertion and extraction force:3.6N Max
Screw torque:42-53 (N.m)
Temperature and humidity:-4080C; 40C, 85%RH

Reliable Power Connection in Demanding Environments

With an IP67 waterproof rating and robust construction, the YM20 12Pin Male Plug is engineered to deliver dependable electrical connections in harsh outdoor and industrial settings. Its durable high-strength plastic shell ensures long-term protection against corrosion, dust, and moisture, making it an ideal choice for applications requiring resilience and safety.

Versatile Applications Across Multiple Industries

This multi-pin connector supports a range of uses including LED lighting installations, automation systems, machinery, and marine applications. Its compatibility with 24-16AWG cables and efficient current and voltage ratings make it suitable for various power distribution needs, ensuring flexibility for designers, engineers, and installers.

Simple and Secure Installation

The connector's cable mount design features solder terminals for reliable and lasting connections. A secure locking mechanism and rubber gasket ring provide an easy yet robust installation process, maintaining waterproof and dustproof integrity while minimizing installation time and effort.

FAQ's of YM20 250V 5A 12Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal:

Q: How do I install the YM20 12Pin Male Plug connector?

A: To install the YM20 connector, strip the ends of your 24-16AWG cables, solder them to the corresponding terminals inside the connector, then secure the plastic shell. The rubber gasket ring should be properly seated to ensure an IP67 waterproof seal, and the locking system provides a secure fit.

Q: What are the main benefits of using this waterproof power connector?

A: This connector offers reliable, high-capacity power connections in harsh conditions, thanks to its IP67 waterproof and dustproof rating, corrosion-resistant nylon PA66 shell, and silver-plated copper alloy contacts. Installation is straightforward, and its robust design ensures safety and longevity.

Q: When should I choose the YM20 12Pin connector for my project?

A: Choose the YM20 connector when you need a secure, weatherproof multi-pin connection outdoors or in industrial environments. It's ideal for applications such as LED lighting systems, automation, marine equipment, and machinery that demand reliable, high-current connections.

Q: Where can the YM20 connector be used effectively?

A: The connector is suited for outdoor and industrial locations, including marine settings, machine installations, automated factories, and LED lighting projects, where it can efficiently withstand exposure to moisture, dust, and varying temperatures.

Q: What process should I follow to maintain the IP67 rating during usage?

A: Ensure that the rubber gasket ring is undamaged and properly installed during setup. After soldering, securely fasten the locking shell to maintain water and dust resistance. Regularly check seals and the housing to preserve the IP67 protection over time.

Q: What kind of power and wire specifications does this connector support?

A: The YM20 supports up to 5A per pin at 250V AC and is compatible with 24-16AWG wires. This makes it suitable for most standard electrical power supply and distribution requirements in demanding environments.

Q: How does this connector contribute to the safety and longevity of equipment?

A: By offering high insulation resistance, low contact resistance, and robust sealing against water, dust, and corrosion, the YM20 connector protects circuits from shorting and environmental damage, thereby extending the life and reliability of your equipment.
