YM24 45A 3Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal

Name: YM24 45A 3Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 966.0 INR
Availability: InStock

966.0 INR/Piece

Get a Price/Quote

Product Details:

Power Source Wired Electrical Connection
Input 3Pin Male Plug
Power Supply Electrical
Components Plastic Shell, 3Pin Solder Terminal, Sealing Ring
Usage Industrial Equipment, Power Transmission
Interface 3Pin Solder Terminal
Features Waterproof, Dustproof, Corrosion Resistant, Easy Installation
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YM24 45A 3Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 966.0 INR/Piece

Material High-grade Plastic, Copper Pins
Sealing Ring Material Silicone Rubber
Mechanical Life >500 Mating Cycles
Insulation Resistance 2000M @ 500V DC
Cable Outer Diameter 10mm - 14mm
Shell Locking Type Screw Locking
Wire Gauge Supported 6-10mm2
Flame Retardant Level UL94 V-0
Contact Resistance 2m

YM24 45A 3Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Product Specifications

Supply Voltage 500V AC/DC
Color Black
Weight 98g
Thickness Standard Shell Wall Thickness
Application Outdoor Power Transmission, Machinery, Automation
Product Type Male Power Connector
Dimension (L*W*H) 71mm x 33mm x 33mm
Current Rating 45A
Power Source Wired Electrical Connection
Size YM24 Shell Size
Power Supply Electrical
Input 3Pin Male Plug
Rated Voltage 500V AC/DC
Usage Industrial Equipment, Power Transmission
Capacity 45A Maximum Current
Components Plastic Shell, 3Pin Solder Terminal, Sealing Ring
Function Power Connection for Electrical Equipment
Interface 3Pin Solder Terminal
Frequency 50/60Hz
IP Rating IP67
Output Cable Connection
Operating Temperature -40C to +80C
Features Waterproof, Dustproof, Corrosion Resistant, Easy Installation

Material High-grade Plastic, Copper Pins
Sealing Ring Material Silicone Rubber
Mechanical Life >500 Mating Cycles
Insulation Resistance 2000M @ 500V DC
Cable Outer Diameter 10mm - 14mm
Shell Locking Type Screw Locking
Wire Gauge Supported 6-10mm2
Flame Retardant Level UL94 V-0
Contact Resistance 2m

YM24 45A 3Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:latching lock
Contact diameter:phi 3.0x3
Operating voltage(AC.V.rms):500V
Withstand voltage(AC.V)1min:2500V
Temperature and humidity:-4080C, 40C, 85%RH
Mating cycle:1700 times

Designed for Durability in Harsh Environments

The YM24 connector boasts an IP67 rating, making it both waterproof and dustproof-perfect for industries requiring robust power transmission in challenging conditions. Its flame-retardant UL94 V-0 plastic shell and corrosion-resistant components offer long-term reliability. The silicone sealing ring adds another layer of protection, ensuring your connections remain intact even with frequent exposure to moisture and debris.

High Capacity and Secure Connection

Supporting up to 45A of current at 500V AC/DC, the YM24 3Pin Male Plug is suitable for high-power applications. The screw locking mechanism delivers a tight, vibration-resistant seal, ideal for heavy-duty and automation equipment. The 3Pin solder terminal interface ensures consistent contact, while the wide cable compatibility (10-14mm outer diameter) and standard shell wall thickness cater to a range of installations.

Easy Installation and Versatile Application

Installation of the YM24 power connector is straightforward, thanks to its wire gauge support of 6-10mm2 and solder terminal design. Used extensively in industrial machinery, automation systems, and outdoor power infrastructure, it simplifies maintenance and ensures a dependable electrical supply. Whether for new projects or retrofitting existing systems, the YM24 guarantees efficiency and safety.

FAQ's of YM24 45A 3Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal:

Q: How do I install the YM24 45A 3Pin Male Plug for a secure power connection?

A: To install, strip the cable to fit the supported wire gauge (6-10mm2) and outer diameter (10-14mm). Solder each wire to its respective pin on the 3Pin solder terminal. Insert the cable through the shell and secure it with the screw locking mechanism. Make sure the silicone sealing ring is in place for optimal waterproofing.

Q: What makes the YM24 connector suitable for outdoor use?

A: The YM24 plug features an IP67 rating, providing complete protection against dust and water ingress. Its flame-retardant (UL94 V-0) plastic shell and corrosion-resistant materials enable reliable performance in harsh outdoor or industrial environments, making it ideal for power transmission in machinery and automation.

Q: When should I use the YM24 3Pin Power Connector?

A: Use the YM24 connector when you need a dependable, high-capacity (up to 45A) connection for electrical equipment, especially in industrial or outdoor settings. It's suitable for applications involving machinery, automation systems, or anywhere robust, waterproof connections are critical.

Q: Where can I apply the YM24 plug in my projects?

A: The connector is ideal for industrial automation, machinery, outdoor power distribution, and any application demanding a reliable, high-current connection. Its design suits both new installations and upgrades in electrical and automation projects.

Q: What are the benefits of using a screw locking type with this connector?

A: The screw locking mechanism ensures a tight, stable connection and prevents accidental disconnection caused by vibration or movement. This feature enhances system safety and minimizes maintenance needs in demanding or mobile applications.

Q: How does the YM24 maintain safety with high voltage and current?

A: The plug uses high-grade plastic insulation, copper contact pins, a robust sealing system, and supports a contact resistance below 2m and insulation resistance of 2000M at 500V DC. These design choices, along with flame-retardant materials, provide secure, dependable operation at 45A and 500V AC/DC.
