YM24 RJ45 Cat5e Female Socket IP67 Waterproof Ethernet Connector

Name: YM24 RJ45 Cat5e Female Socket IP67 Waterproof Ethernet Connector
Brand: CONNECTOR DEVICES
Price: 450.0 INR
Availability: InStock

450.0 INR/Piece

Get a Price/Quote

Product Details:

Response Time Low latency, <1ms
Components Socket, Cap, Gasket, Locknut
Usage Network / Outdoor Ethernet Connection
Features IP67 Waterproof, Dustproof, Panel Mount, UV Resistant
IP Rating IP67
Operating Temperature -40C to +85C
Input RJ45 Cat5e Female
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YM24 RJ45 Cat5e Female Socket IP67 Waterproof Ethernet Connector Price And Quantity

Minimum Order Quantity 100 Piece
Price 450.0 INR/Piece

Contact Material Phosphor Bronze, Gold Plated
Mounting Type Panel Mount with Locknut
Flame Resistance UL94V-0
Number of Contacts 8
Ingress Protection Waterproof & Dustproof to IP67 when mated
Sealing Type Silicone O-Ring Gasket
Mating Cycles 500 times
Cable Compatibility Cat5e/ Cat6, 24-26 AWG
Standards Compliance TIA/EIA 568-B.2, ISO/IEC 11801
Protection Cap Included Yes
Connector Gender Female to Female
Shell Material Zinc Alloy with Nickel Plating
Data Rate Up to 100 Mbps (Cat5e Standard)

YM24 RJ45 Cat5e Female Socket IP67 Waterproof Ethernet Connector Product Specifications

Thickness Panel thickness 1-10 mm (Recommended Mounted)
Application Industrial Ethernet, Outdoor Networks, Surveillance systems
Input RJ45 Cat5e Female
Function RJ45 Ethernet Signal Transmission
Power Supply Not Applicable (Data Only)
Interface RJ45 Cat5e (8P8C)
Dimension (L*W*H) Approx. 38 x 38 x 34 mm
Power Source None (Passive)
IP Rating IP67
Operating Temperature -40C to +85C
Rated Voltage AC 250V / 60V DC Max
Resolution Up to 100 Mbps (Fast Ethernet)
Product Type RJ45 Cat5e Waterproof Connector
Output RJ45 Cat5e Female
Frequency 50/60 Hz Supported
Current Rating 1.5A Max
Response Time Low latency, <1ms
Weight Approx. 60g
Supply Voltage Not applicable (Data interface only)
Components Socket, Cap, Gasket, Locknut
Usage Network / Outdoor Ethernet Connection
Features IP67 Waterproof, Dustproof, Panel Mount, UV Resistant
Color Black / Silver Metallic
Size M24 Panel Mount

Contact Material Phosphor Bronze, Gold Plated
Mounting Type Panel Mount with Locknut
Flame Resistance UL94V-0
Number of Contacts 8
Ingress Protection Waterproof & Dustproof to IP67 when mated
Sealing Type Silicone O-Ring Gasket
Mating Cycles 500 times
Cable Compatibility Cat5e/ Cat6, 24-26 AWG
Standards Compliance TIA/EIA 568-B.2, ISO/IEC 11801
Protection Cap Included Yes
Connector Gender Female to Female
Shell Material Zinc Alloy with Nickel Plating
Data Rate Up to 100 Mbps (Cat5e Standard)

YM24 RJ45 Cat5e Female Socket IP67 Waterproof Ethernet Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Modular Interface:RJ45
Gender:Male
Operating Voltage:125V
Withstand Voltage:1000V
Temperature and humidity:-4080C, 40C, 85%RH
Mating cycle:1700 times
Standard:Cat5e

Superior Environmental Protection

This connector provides full IP67 waterproof and dustproof protection when mated, making it ideal for outdoor and industrial Ethernet applications. The silicone O-ring gasket and sealed design ensure network reliability even in wet, dusty, or extreme weather conditions.

Easy Panel Mount Installation

The YM24 RJ45 socket features a convenient panel mount format with an included locknut, supporting panel thicknesses from 1 to 10 mm. Installation is straightforward, allowing quick integration into network equipment, control panels, or outdoor enclosures.

Enhanced Performance and Durability

Constructed with a zinc alloy shell and gold-plated phosphor bronze contacts, this connector guarantees high durability, corrosion resistance, and dependable data transmission. With support for up to 500 mating cycles, it is well-suited for repeated connections and demanding environments.

FAQ's of YM24 RJ45 Cat5e Female Socket IP67 Waterproof Ethernet Connector:

Q: How do I install the YM24 RJ45 Cat5e Female Socket in a panel setup?

A: To install, drill an appropriate-sized hole in your panel (1-10 mm thick recommended), insert the socket from the front, and secure it using the included locknut from the back. Ensure the silicone O-ring gasket is positioned correctly for proper sealing before tightening.

Q: What types of Ethernet cables are compatible with this connector?

A: This socket is compatible with standard Cat5e and Cat6 Ethernet cables, supporting wire sizes between 24 and 26 AWG. It is suitable for both indoor and outdoor-rated cables with RJ45 (8P8C) terminations.

Q: When is the IP67 rating effective for this Ethernet connector?

A: The IP67 waterproof and dustproof rating is achieved when the connector is properly mated (connected) and the protection cap is secured while unplugged. This provides complete environmental protection for outdoor or industrial applications.

Q: Where can I use the YM24 RJ45 Cat5e Female Socket?

A: This connector is designed for network connections in challenging environments such as industrial automation systems, outdoor surveillance cameras, marine networking, and other locations exposed to moisture, dust, or UV radiation.

Q: What benefits does the gold-plated phosphor bronze contact material provide?

A: Gold-plated phosphor bronze contacts offer excellent corrosion resistance, enhance signal integrity, and ensure low contact resistance. This results in more reliable data transmission, especially in harsh or corrosive environments.

Q: How many times can the connector be mated and unmated without loss of performance?

A: The YM24 RJ45 socket is rated for up to 500 mating cycles, allowing for frequent connection and disconnection while maintaining optimal performance.

Q: Does this connector provide power transmission or data only?

A: This connector is for data transmission only and does not support power supply functions. It is designed to handle Ethernet signal transmission up to 100 Mbps (Cat5e standard).
