19 Pin HDMI Male Solder Type (HDMI-19P-4145)

Get a Price/Quote

Product Details:

Connector HDMI 19 Pin Male Solder Type
Pairs Twisted Pairs (for differential signals)
Voltage Rating 30V Max
Application Audio/Video Equipment, HDTV, Monitor, Projector
Capacity High-Speed Data Transmission
Male End Type HDMI 19 Pin Male
Female End Type N/A (Male to Solder Termination)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

19 Pin HDMI Male Solder Type (HDMI-19P-4145) Price And Quantity

Minimum Order Quantity 100 Piece

19 Pin HDMI Male Solder Type (HDMI-19P-4145) Product Specifications

Male End Type HDMI 19 Pin Male
Length Custom/As Required
Connector HDMI 19 Pin Male Solder Type
Female End Type N/A (Male to Solder Termination)
Flame Resistance Level VW-1
Material Gold-Plated Copper Contacts, Metal Shell, Thermoplastic Housing
Jacket Material PVC
Outer Diameter ~7.3mm
Cable Length As Required
Color Black
Sheild Yes, Shielded
Wire Gauge 28 AWG Supported
Capacity High-Speed Data Transmission
Temperature -20C to +80C
Voltage Rating 30V Max
Number of Conductor 19
Application Audio/Video Equipment, HDTV, Monitor, Projector
Cable Type HDMI
Connector Type Solder Type
Pairs Twisted Pairs (for differential signals)
Insulation PE Insulated

Supported Resolutions Up to 4K Ultra HD (dependent on cable)
Packaging Bulk or Customized Packaging
Mounting Style Cable Mount (Solder Type)
Locking Mechanism Standard friction fit
Impedance 100 Differential Impedance
Insulation Resistance >100M at 500V DC
Durability Over 5000 mating cycles
RoHS Compliance Yes
Contact Resistance <10m Max
Compatibility Compliant with HDMI 1.4 / 2.0 standards

Product Description

Jump on the next level of connectivity with the flawless 19 Pin HDMI Male Solder Type (HDMI-19P-4145). Engineered with valorous gold-plated copper contacts and a grand metal shell, this special connector is designed for premium performance in demanding audio/video setups. Supporting up to 4K Ultra HD (dependent on cable quality) and built to withstand over 5000 mating cycles, it guarantees lasting reliability. Enjoy peace of mind with RoHS compliance, high insulation resistance, shielded signal pairs, and versatile cable mount style. Perfect for manufacturers, traders, and importers across India seeking robust, customizable HDMI solutions.

Versatile Interface for Professional Applications

The 19 Pin HDMI Male Solder Type (HDMI-19P-4145) stands out for its use in audio/video equipment such as HDTVs, monitors, and projectors. This solder-type connector is designed for cable professionals, technicians, and AV integrators who demand high-speed data transmission and dependable signal integrity. It is widely used by distributors, exporters, wholesalers, and manufacturers who require a reliable HDMI termination option for customized cable assemblies and professional installations.

Premium Payment Options & Reliable Supply

Enjoy flexible payment terms at special rates for bulk orders of the HDMI-19P-4145. Premium quality is assured with exchange and sample options available to meet your requirements before bulk purchase. Our robust supply ability covers large-scale and time-sensitive demands, ensuring your inventory remains grand and uninterrupted. Secure your supply with reliable distribution from trusted sources across India, whether you are a manufacturer, trader, or wholesaler seeking top-tier HDMI connectors.

FAQ's of 19 Pin HDMI Male Solder Type (HDMI-19P-4145):

Q: How is the 19 Pin HDMI Male Solder Type (HDMI-19P-4145) typically used?

A: This connector is soldered onto custom cables for high-speed AV transmission in applications such as TV installations, monitors, projectors, and audio/video equipment. It is ideal for scenarios requiring robust signal integrity and flexible cable lengths.

Q: What are the specific benefits of using this solder type HDMI connector?

A: The solder type design enables tailored cable assemblies, superior durability with over 5000 mating cycles, and gold-plated contacts for flawless signal transfer. It also supports shielded connections and high-speed data rates.

Q: When should I choose this HDMI connector over pre-molded types?

A: Opt for the solder-type HDMI connector when you need a custom cable length, particular wire gauge, or must perform field repairs and installations in unique scenarios where factory-terminated cables are not suitable.

Q: Where is this HDMI connector commonly utilized?

A: It is widely used in professional AV environments-such as broadcast studios, conferencing systems, custom AV setups, and home theaters-where reliability and signal quality are paramount.

Q: What is the process for obtaining samples and bulk orders?

A: You can request premium samples to evaluate before placing a bulk order. Special exchange rates and flexible terms are available through verified distributors, exporters, and wholesalers across India.
