LP20 20A 3Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal

Name: LP20 20A 3Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 432.0 INR
Availability: InStock

432.0 INR/Piece

Get a Price/Quote

Product Details:

Operating Temperature -40C to +85C
Output Panel mounted female socket
Power Supply AC / DC
Power Source Panel / device power feed
Features Metal body, waterproof, dustproof, corrosion-resistant, vibration resistant
Input 3-pin female solder terminal
Interface Solder Terminal
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 20A 3Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Price And Quantity

Price 432.0 INR/Piece
Minimum Order Quantity 100 Piece

LP20 20A 3Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Product Specifications

Size M20 Thread
Color Silver / Black
Features Metal body, waterproof, dustproof, corrosion-resistant, vibration resistant
Rated Voltage 500V AC
Usage Power distribution, equipment interconnection
Weight Approx. 70g
Power Source Panel / device power feed
Frequency 50/60Hz
Product Type Waterproof Power Connector Socket
Power Supply AC / DC
Components Metal flange mount, solder cups, sealing ring
IP Rating IP67
Function Power Connector Socket
Supply Voltage Up to 500V AC
Operating Temperature -40C to +85C
Output Panel mounted female socket
Capacity 20A Max Current
Application Industrial equipment, outdoor power system, machinery
Thickness Shell wall approx. 2mm
Input 3-pin female solder terminal
Interface Solder Terminal
Dimension (L*W*H) Flange 32mm x 32mm, overall length 51mm
Current Rating 20A

Insulation Resistance > 2000 M at 500V DC
Environmental Protection UV and oil resistant
Mounting Type Flange panel mount
Mating Style Bayonet locking mechanism
Dielectric Withstanding Voltage 1500V AC/min
Life Cycle > 500 mating cycles
Standards Compliance RoHS compliant
Contact Material Copper alloy with gold plating
Material Zinc alloy shell with nickel plating
Number of Contacts 3-pins
Cable Specification Supports cable OD 6-12mm
Sealing Silicone gasket included

LP20 20A 3Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Experience instant savings and unbeatable price with the LP20 20A 3Pin Female Socket, a power connector that blends opulent design with distinguished, robust performance. Featuring a lofty zinc alloy shell with nickel plating, this cost-effective connector boasts a corrosion-resistant, waterproof, and dustproof IP67 rating. The bayonet locking mechanism ensures secure mating, while gold-plated copper contacts provide superior conductivity. Engineered for industrial excellence, this socket is RoHS compliant and designed for intense environments, delivering reliable power distribution for machinery and outdoor systems at a maximal 20A and 500V AC rating.

Competitive Advantages & Applications

The LP20 20A 3Pin Female Socket stands out with its distinguished corrosion-resistant design and cost-effective durability, perfect for harsh industrial settings. Its robust metal body ensures performance in automated plants, outdoor machinery, and power distribution systems. Used by manufacturers, exporters, and industrial automation professionals, this socket guarantees connectivity under demanding conditions, offering secure integration for panel builders, OEMs, and equipment installers across India and beyond.

Payment Terms, Certifications & Delivery

Purchase orders for the LP20 20A 3Pin Female Socket are processed with quick dispatch and reliable transportation solutions. Certified to meet RoHS compliance standards, every connector meets international quality benchmarks. We ensure prompt delivery times, fulfilling orders across varied industries efficiently. Our seamless order processing and shipping system guarantee that you'll receive your product securely and on schedule, reinforcing our commitment to customer satisfaction and operational excellence.

FAQ's of LP20 20A 3Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal:

Q: How is the LP20 20A 3Pin Female Socket installed?

A: The LP20 socket is mounted on a flange panel using standard screws. Its bayonet locking mechanism ensures a secure, vibration-resistant connection, and the solder terminal interface allows for straightforward wire attachment.

Q: What applications is this connector most suitable for?

A: This connector is ideal for industrial equipment, outdoor power systems, and heavy machinery where waterproofing, durability, and high-current supply are necessary. It is widely used for reliable power distribution and equipment interconnection in rigorous environments.

Q: When can I expect delivery after placing a purchase order?

A: Orders are processed promptly with quick dispatch. Delivery times depend on your location and shipping preference, but we prioritize fast, reliable transportation to ensure your connector arrives efficiently.

Q: Where does the product's IP67 rating provide an advantage?

A: The IP67 rating makes this connector especially advantageous for outdoor and industrial environments exposed to water, dust, oil, and UV, guaranteeing reliable operation even under harsh conditions.

Q: What are the benefits of choosing the LP20's metal shell design?

A: The zinc alloy shell with nickel plating delivers corrosion resistance, mechanical strength, and a professional, opulent finish, ensuring long-term, cost-effective use in demanding settings.

Q: How does the connector ensure safety and compliance?

A: This model is RoHS compliant and features a silicone gasket for sealing, high dielectric strength, and insulation resistance over 2000 M at 500V DC, ensuring safe, high-quality electrical performance.
